5

ENGLISH



Attention! Do not place the unit near bath tubs,
kitchen  sinks  or  other  containers  filled  with
water.

1.  Set the lid blocking handle (16) to the position  .
2.  Open  the  multicooker  lid  (10)  by  pressing  the  but-

ton (2).

3.  Unscrew  the  clamp  (8)  and  remove  the  protection

screen (9).

4.  Remove  the  steam  valve  (17)  and  dissemble  it  by

turning its lower part counterclockwise.

5.  Remove the drip tray (13).
6.  Wash all the removable parts (steam valve (17) parts,

protection screen (9), bowl (3), basket for steam cook-
ing (18), soup ladle (20), spatula (21), measuring cup
(19), yogurt cups and small lids (23)) with a soft sponge
with some neutral detergent, then rinse and dry.

7.  Scald  the  yogurt  cups  and  small  lids  (23)  before

making yogurt.

8.  Wipe  the  unit  body  with  a  soft  damp  cloth.  Let  the

unit dry.

9.  Combine the valve parts by matching ledges on the

lower  part  with  grooves  on  the  upper  one  and  turn
the lower part clockwise till locking.

10. Install  the  protection  screen  (9)  and  fix  it  with  the

clamp (8), screw it, rotating clockwise.

11.  Install  the  drip  container  (13)  and  the  steam  valve

(17) back to its place.

USING
Control panel



Every  pressing  of  the  control  panel  buttons  is
accompanied by a sound signal.

«MULTICOOKER» mode

Attention!



Never leave the operating unit unattended.



To avoid burns be very careful when opening the
multicooker lid (10), do not bend over the steam
release  openings  during  the  unit  operation  and
do not place open parts of your body above the
bowl (3)!



During  the  first  operation  of  the  multicooker
some  foreign  smell  from  the  heating  element
can appear. It is normal.



Do  not  use  metal  objects  that  can  scratch  the
non-stick coating of the bowl (3).

1.  Set the lid blocking handle (16) to the position  .
2.  Open the multicooker lid (10) by pressing the button

(2). Remove the bowl (3) from the multicooker pro-
cess chamber.

3.  Load the products into the bowl (3) according to the

recipe (see “Recipe book”).

Note:





Make  sure  that  the  products  and  liquids  level  in
the  bowl  (3)  does  not  exceed  the  level  of  maximal
mark  «10»  and  is  not  lower  than  the  level  of  mini-
mal mark «2».





Maximal  level  mark  for  porridges  (except  rice)  is
«8».

General  example  of  loading  products  and  water
(as example rice is considered)



Measure rice with the measuring cup (19) (one mea-
suring cup is equal to approximately 160 g of rice),
wash it and put in the bowl (3).





Water level required for certain amount of rice (mea-
sured in cups «CUP») is given in the scale inside the
bowl (3).





Pour water up to the corresponding mark.

Example



After putting four measuring cups of rice, pour water
till the mark «4 CUP».





For  thin  milk  porridges  the  recommended  propor-
tion of rice and water is 1:3.

4.  Put  the  bowl  (3)  into  the  process  chamber.  Make

sure  that  the  outer  surface  of  the  bowl  is  clean  and
dry,  and  the  bowl  itself  is  placed  evenly  and  has
secure contact with heating element (4) surface.

Note:



Do not use the bowl (3) for washing cereals and do
not  chop  products  in  it,  this  can  damage  the  non-
stick coating;



Make  sure  that  there  are  no  foreign  objects,  dirt  or
moisture in the process chamber and on the bottom
of the bowl (3);



Wipe  the  outer  surface  and  the  bottom  of  the  bowl
(3) dry before use.



In  the  middle  of  the  heating  element  (4)  there  is  a
temperature  sensor  (5).  Make  sure  that  the  move-
ment of the sensor is not limited.

5.  If  you  steam  products,  pour  water  into  the  bowl  (3)

so that boiling water doesn’t reach the bottom of the
basket  (18).  Put  the  food  into  the  basket  (18)  and
place it on the bowl (3).

6.  Close the lid (10) until click.
7.  Insert  the  power  cord  jack  into  the  connector  (12)

and  the  power  cord  plug  into  the  socket.  There  will
be  a  sound  signal,  the  display  (15)  will  show  sym-
bols «--:--».

Note:



If you don’t use the unit for 30 seconds, it is switched
to  the  stand-by  mode  automatically,  there  will  be  a
sound  signal,  operation  mode  symbols  will  go  out
and the display will show symbols «- -».



Set the lid blocking handle (16) to the position  .

8.  Press  the  button  (29)  «MENU»,  the  flashing

«Roasting»  program  symbol  and  the  time  symbols
«0:25» will appear on the display.

9.  Select  the  necessary  program  by  consequently

pressing  the  button  (29)  «MENU»  or  the  buttons
(27)  «-»  and  (30)  «+».  The  corresponding  program
symbol will be flashing, the operation time and cook-
ing pressure set by default also will be shown on the
display (see «Cooking programs» table).
