02/ 2018
BENNING MM P3
19
Measuring range
Resolution
Measuring accuracy
50 nF
10 pF
± (5.0 % of the measured value + 0.2 nF)*
500 nF
100 pF
± (2.9 % of the measured value + 5 digits)
5 µF
1 nF
± (2.9 % of the measured value + 5 digits)
50 µF
10 nF
± (2.9 % of the measured value + 5 digits)
100 µF
100 nF
± (2.9 % of the measured value + 5 digits)
The measuring duration depends on the capacitor size and might take up to 20 seconds.
* The measuring accuracy is specified for measured values from 10 nF and for previ-
ous null balance by means of the „RANGE/ REL Δ (
)“ key
6
7.6 Frequency ranges
Overload protection for frequency measurements: 600 V
eff
7.6.1 Frequency ranges for square wave signals (Switch setting: Hz, %)
Measuring
range
Resolution
Measuring accuracy for 5 V
SS
max.
(square wave signal)
Sensitivity
5 Hz
0.001 Hz
± (0.3 % of the measured value + 5 digits) > 1.0 V
ss
(rectangle)
50 Hz
0.01 Hz
± (0.3 % of the measured value + 5 digits) > 1.0 V
ss
(rectangle)
500 Hz
0.1 Hz
± (0.3 % of the measured value + 5 digits) > 1.0 V
ss
(rectangle)
5 kHz
1 Hz
± (0.3 % of the measured value + 5 digits) > 1.0 V
ss
(rectangle)
50 kHz
10 Hz
± (0.3 % of the measured value + 5 digits) > 1.0 V
ss
(rectangle)
500 kHz
100 Hz
± (0.3 % of the measured value + 5 digits) > 1.0 V
ss
(rectangle)
5 MHz
1 kHz
± (0.3 % of the measured value + 5 digits) > 1.0 V
ss
(rectangle)
7.6.2 Frequency indication for sinusoidal signals (Switch setting: V
AC
, Hz, %) and
actuation of the „SELECT“ key:
Measuring accuracy: ± (0.3 % + 5 digits) applies to sinusoidal voltages of up
to 600 V
eff
(10 Hz - 500 Hz) and displayed values in the AC voltage range
(V
AC
) higher than 50 % of the final measuring range value
7.7 Pulse duty ratio for square wave signals
(Switch setting: Hz, %)
Overload protection in the case of pulse ratio measurement: 600 V
eff
Meas. range
Resolution
Measuring accuracy up to 5 V
SS
(square wave signal, 5 Hz - 5 kHz)
Sensitivity
(30 % ≤ % ≤ 70 %)
0.1 % - 99.9 %
0.1 %
± (0.5 % of the measured value + 3 digits) > 1.0 V
ss
(rectangle)
8. Measuring with the BENNING MM P3
8.1 Preparing the measurement
Operate and store the BENNING MM P3 at the specified storage and operating tem
-
peratures only! Do not permanently expose the device to sunlight.
- The connected black and red safety measuring leads comply with the valid provi-
