02/ 2018
BENNING MM P3
16
5. General information
5.1 General information on the multimeter
5.1.1 The digital display
is a 3
5
/
6
-digit LC display with a font size of 14 mm and
a decimal point. The highest numerical value to be displayed is 5000.
5.1.2 The polarity indication
works automatically. Only a polarity contrary to the
connection definition is indicated with “-“.
5.1.3 The range exceedance is indicated by “ 0L“ or “- 0L“ and partly by an acoustic
warning.
Attention, no indication and warning in case of overload!
5.1.4 Measured value storage „HOLD“: Press the “HOLD“ key
4
to store the
measuring result. At the same time, the display shows the “HOLD“ symbol.
Press the key again to switch back to the measuring mode.
5.1.5 By means of the „SELECT“ key
5
, the secondary or third function of the
rotary switch position can be selected.
Note:
- Function % describes the pulse duty factor of periodic signals: [%] = T
1
T
5.1.6 The „RANGE“ key
6
is intended for shifting the manual measuring ranges and
masking the „AUTO“ symbol on the display at the same time. Select the automatic
range selection by pressing the key for approx. 1 second („AUTO“ is shown on the
display). In the
position of the rotary switch, a relative value function „REL ∆“ is
assigned to the „RANGE“ key. By pressing the key, the applying measured value
is stored and the difference (offset) between the stored measured value and the
following measured values is displayed. The relative value function „REL ∆“ allows
a null balance of the capacity range with the measuring leads not being connected.
By pressing the key, the device is switched back to normal operating mode.
5.1.7 The nominal measuring rate of the BENNING MM P3 is 3 measurements per
second for the digital display.
5.1.8 The BENNING MM P3 can be switched on or off by means of the rotary
switch
7
. Switched off: position „OFF“.
5.1.9 The BENNING MM P3 switches off automatically after approx. 30 minutes
(
APO
,
A
uto-
P
ower-
O
ff). Automatic switch-off can be deactivated by pressing
the „RANGE“ key and by simultaneously switching on the BENNING MM P3
from the switching position „OFF“.
5.1.10 Temperature coefficient of the measured value: 0.2 x (stated measuring ac
-
