BENNING MM P3
15
Before starting the current clamp multimeter, always check the de-
vice as well as all measuring leads for damages.
If it can be assumed that safe operation is no longer possible, switch the device off
immediately and secure it against unintended operation.
Safe operation can be assumed to be no longer possible, if
- the device or the measuring leads exhibit visible damages,
- the device no longer works,
- the device has been stored under unfavourable conditions for a longer period of time,
- the device was exposed to extraordinary stress during transport,
- if the device or the measuring leads are exposed to moisture.
In order to prevent danger
- do not touch the bare measuring probe tips of the measuring
leads
3. Scope of delivery
The scope of delivery of the BENNING MM P3 comprises:
3.1 One BENNING MM P3, with firmly connected attached safety measuring
leads, black and red (L = 0.6 m, tip Ø 2 mm)
3.2 One protective case,
3.3 Two 1.5 V (LR44) batteries are integrated into the device,
3.4 One operating manual.
Parts subject to wear:
- The BENNING MM P3 is supplied by means of two integrated 1.5 V batteries
(LR44).
4. Device description
See figure 1:
Device front
The display and operating elements shown in figure 1 are designated as follows:
Digital display
, displaying measured value and range exceedance,
Polarity indication
,
Battery indication
, appears in case of discharged battery,
4
HOLD key
, storage of the displayed measured value,
5
SELECT
key
for selecting the secondary or tertiary function,
6
RANGE key
, switch-over between automatic/ manual measuring range,
7
Rotary switch
, for selecting the measuring function,
8
Safety measuring lead (red),
positive
1
connection for
V, Ω,
, Hz,
9
COM safety measuring lead (black),
common connection for voltage/ resist-
ance/ frequency/ pulse duty factor/ capacity measurements, continuity and diode
tests,
1
) This is what the automatic polarity indication for DC voltage refers to
