02/ 2018
BENNING MM P3
17
curacy)/ °C < 18 °C or > 28 °C, related to the value for the reference tempera-
ture of 23 °C.
5.1.11 The BENNING MM P3 is supplied by means of two 1.5 V batteries (LR44).
5.1.12 If the battery voltage falls below the specified operating voltage of the BEN
-
NING MM P3, a battery symbol
appears on the display
.
5.1.13 The battery life is approx. 100 hours (alkaline battery).
5.1.14
Dimensions of the device: (L x W x H) = 132 x 86 x 19 mm with protective case
Weight: 130 g with protective case and batteries
5.1.15 The safety measuring leads are designed in 2 mm plug-in technology. The
connected safety measuring leads comply with the nominal voltage of the
BENNING MM P3.
6. Ambient conditions
- The BENNING MM P3 is intended for measurements under dry ambient condi-
tions,
- Maximum barometric height for measurements: 2000 m,
- Overvoltage category / installation category: IEC 60664-1/ IEC 61010-1 → 300 V
category III; 600 V category II,
- Contamination class: 2,
- Protection category: IP 30 DIN VDE 0470-1 IEC/EN 60529
IP 30 means: Protection against access to dangerous parts and protection
against solid impurities of a diameter > 2.5 mm, (3 – first index).
No protection against water, (0 – second index).
- Operating temperature and relative air humidity:
For operating temperatures from 0 °C to 30 °C: relative air humidity less than 80 %,
For operating temperatures from 31 °C to 40 °C: relative air humidity less than 75 %,
For operating temperatures from 41 °C to 50 °C: relative air humidity less than 45 %,
- Storage temperature: The BENNING MM P3 can be stored at temperatures be-
tween - 20 °C and + 60 °C (air humidity of 0 to 80 %). During storage, the bat-
teries should be removed.
7.
Electrical specifications
Note: The measuring accuracy is specified as the sum of:
- a relative part of the measured value and
- a number of digits (i.e. counting steps of the last digit).
This measuring accuracy applies for temperatures from 18 °C to 28 °C and a relative
air humidity less than 80 %.
7.1 DC voltage ranges
(Switch setting: V
DC
mV
DC
)
The input resistance is 10 MΩ.
Measuring range Resolution
Measuring accuracy
Overload
protection
400 mV
0.1 mV
± (0.7 % of the measured value + 5 digits)
600 V
DC
4 V
1 mV
± (0.6 % of the measured value + 2 digits)
600 V
DC
40 V
10 mV
± (0.6 % of the measured value + 2 digits)
600 V
DC
