The high pressure jet must not be direct-
ed at persons, animals, live electrical
equipment or at the appliance itself.
Protect the appliance against frost.

Illustrations on Page 2

1

Transport handle

2

Trigger gun

3

Lock trigger gun

4

Key to detach the high pressure hose from the trig-
ger gun

5

Storage for trigger gun
Storage for high pressure hose

6

High pressure hose

7

Detergent suction hose (with sieve)

8

Spray lance with pressure regulation (Vario Power)

9

Thermostat valve

10 High pressure connection
11 Coupling element for water connection
12 Connection for water supply with filter
13 Storage for spray lance
14 Spray lance with Dirtblaster
15 Motor; see operations instructions of the motor

manufacturer

16 Operating instructions for the motor

Special accessories expand the possibilities of using
your appliance. Please contact your KÄRCHER dealer
for further information.

Mount loose parts delivered with appliance prior to start-
up.

Illustrations on Page 2

Illustration



Fasten the transport handle to the frame.
Align the holes in such a way that the screws can
pass through and then fasten the nuts.

Illustration



Attach the accessories holder.

Illustration



Push the high pressure hose into the trigger gun
until it locks audibly.

Note:

 Make sure the connection nipple is aligned

correctly.

 According to applicable regulations, the ap-
pliance must never be used on the drinking
water net without a system separator. A suit-
able system separator by KÄRCHER or al-
ternatively a system separator according to
EN 12729 type BA must be used.
Water that was flowing through a system separator is
considered non-drinkable.

몇

CAUTION

Always connect the system separator to the water sup-
ply, never directly to the appliance!

Note:

 Impurities in the water can damage the high-pres-

sure pump and accessories. For protection, the use of
the KÄRCHER water filter (optional accessory, order
no. 4.730-059) is recommended.

Observe regulations of water supplier.
For connection values, see type plate/technical data.



Use a fibre-reinforced water hose (not included)
with a standard coupling. (Minimum diameter 1/2
inch (13 mm), minimum length 7.5 m).



Screw the coupling element to the water connec-
tion on the appliance.



Push the water supply hose onto the coupling unit,
then connect it to the water supply.

This high-pressure cleaner is suited to work with the
KÄRCHER suction hose with backflow valve (Optional
accessory, order no. 4.440-238) to draw in surface wa-
ter, e.g. from water butts or ponds (see specifications for
max. suction height).



Fill the KÄRCHER suction hose with backflow
valve with water, screw to water supply and hang
into the water butt.



Separate the high pressure hose from the high
pressure connection of the appliance.



Appliance ventilation.
Let the appliance run when the high-pressure hose
is not connected and run it until the water which dis-
charges from the high-pressure outlet is free of
bubbles. Switch off appliance and reconnect high-
pressure hose.

몇

CAUTION

Dry running of more than 2 minutes leads to damage of
the high-pressure pump. If the appliance does not build
up pressure within 2 minutes, switch the appliance off
and proceed in accordance with the instructions in
Chapter "Troubleshooting".

몇

CAUTION

The device is delivered without engine oil. Please fill in
engine oil before using the appliance for the first time.



Fill up the fuel tank and check the oil level.

See Operating Instructions of motor.



Connect the high pressure hose to the high pres-
sure connection of the appliance.



Push the spray lance into the trigger gun and fasten
it by turning it through 90°.



Completely open the water tap.



Start the motor.

See Operating Instructions of motor.

Symbols on the machine

Risk of burns on account of hot surfac-
es!

Risk of poisoning! Do not inhale ex-
haust fumes.

Operation

Description of the Appliance

Special accessories

Before Startup

Water supply

Water supply from mains

Drawing in water from open reservoirs

Start up
