GA-MA770T-UD3/US3 Motherboard

- 74 -

B.

Configuring SATA controller mode in BIOS Setup

Make sure to configure the SATA controller mode correctly in system BIOS Setup .

Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST (Power-On Self-Test).
Ensure  OnChip SATA Controller is enabled under Integrated Peripherals. To enable RAID for the
SATA2_0/1/2/3 connectors, set  OnChip SATA Type  to  RAID. To enable RAID for the SATA2_4/
SATA2_5 connectors, set  OnChip SATA Type  to RAID and set OnChip SATA Port4/5 Type  to As
SATA Type (Figure 1).

The BIOS Setup menus described in this section may differ from the exact settings for your
motherboard. The actual BIOS Setup menu options you will see shall depend on the motherboard
you have and the BIOS version.

Step 2:
Save changes and exit BIOS Setup.

Figure 1

CMOS Setup Utility-Copyright (C) 1984-2009 Award Software

Integrated Peripherals

OnChip IDE Channel

[Enabled]

Onboard 1394 Function

[Enabled]

Onboard LAN Function

[Enabled]

Onboard LAN Boot ROM

[Disabled]



SMART LAN

[Press Enter]

OnChip SATA Controller

[Enabled]

OnChip SATA Type

[ R A I D ]

OnChip SATA Port4/5 Type

[As SATA Type]

Onboard Audio Function

[Enabled]

OnChip USB Controller

[Enabled]

USB EHCI Controller

[Enabled]

USB Keyboard Support

[Enabled]

USB Mouse Support

[Disabled]

Legacy USB storage detect

[Enabled]

Onboard Serial Port 1

[3F8/IRQ4]

Onboard Parallel Port

[378/IRQ7]

Parallel Port Mode

[SPP]

x ECP Mode Use DMA

   3



: Move

Enter: Select

+/-/PU/PD: Value

F10: Save

ESC: Exit

F1: General Help

       F5: Previous Values

F6: Fail-Safe Defaults

F7: Optimized Defaults

Item Help

Menu Level


