- 4 -
Table of Contents
Box Contents ................................................................................................................. 6
Optional Items ................................................................................................................. 6
GA-MA770T-UD3/US3 Motherboard Layout .................................................................. 7
Block Diagram ................................................................................................................ 8
Chapter 1 Hardware Installation .................................................................................... 9
1-1
Installation Precautions ..................................................................................... 9
1-2
Product Specifications .................................................................................... 10
1-3
Installing the CPU and CPU Cooler .............................................................. 13
1-3-1
Installing the CPU ................................................................................................ 13
1-3-2
Installing the CPU Cooler ................................................................................... 15
1-4
Installing the Memory ..................................................................................... 16
1-4-1
Dual Channel Memory Configuration ................................................................ 16
1-4-2
Installing a Memory ............................................................................................. 17
1-5
Installing an Expansion Card ......................................................................... 18
1-6
Back Panel Connectors ................................................................................. 19
1-7
Internal Connectors ........................................................................................ 21
Chapter 2 BIOS Setup ................................................................................................. 33
2-1
Startup Screen ................................................................................................ 34
2-2
The Main Menu .............................................................................................. 35
2-3
MB Intelligent Tweaker(M.I.T.) ....................................................................... 37
2-4
Standard CMOS Features ............................................................................. 42
2-5
Advanced BIOS Features .............................................................................. 44
2-6
Integrated Peripherals ..................................................................................... 46
2-7
Power Management Setup ............................................................................. 50
2-8
PC Health Status ........................................................................................... 52
2-9
Load Fail-Safe Defaults ................................................................................... 54
2-10 Load Optimized Defaults ................................................................................. 54
2-11 Set Supervisor/User Password ..................................................................... 55
2-12 Save & Exit Setup ......................................................................................... 56
2-13 Exit Without Saving ....................................................................................... 56
