GA-MA770T-UD3/US3 Motherboard

- 38 -

Advanced Clock Calibration

Allows you to determine whether to enable Advanced Clock Calibration when using an AMD Black
Edition CPU. We recommend that you enhance heat dissipation for the CPU VRM area if you
enable this function.

Disabled

Disables this function. (Default)

Auto

Lets the BIOS to configure the settings to defaults.

All Cores

Configures Advanced Clock Calibration for all CPU cores.

Per Core

Individually configures Advanced Clock Calibration for each CPU core.

Value (All Cores)

This option is configurable only when Advanced Clock Calibration is set to All Cores.
Options are: -12%~+12%.

Value (Core 0), Value (Core 1), Value (Core 2), Value (Core 3)

This option is configurable only when Advanced Clock Calibration is set to Per Core.
Options are: -12%~+12%.

CPU Clock Ratio

Allows you to alter the clock ratio for the installed CPU. The adjustable range is dependent on the
CPU being used.

CPU NorthBridge Freq.

Allows you to alter the North Bridge controller frequency for the installed CPU. The adjustable
range is dependent on the CPU being used.

CPU Host Clock Control

Enables or disables the control of CPU host clock. Auto (default) allows BIOS to automatically
adjust the CPU host frequency. Manual  allows the CPU Frequency  (Mhz)  item below to be
configurable. Note: If your system fails to boot after overclocking, please wait for 20 seconds to
allow for automated system reboot, or clear the CMOS values to reset the board to default values.

CPU Frequency (MHz)

Allows you to manually set the CPU host frequency.  The adjustable range is from 200 MHz to
500 MHz.
Important It is highly recommended that the CPU frequency be set in accordance with the CPU
specifications.

PCIE Clock (MHz)

Allows you to manually set the PCIe clock frequency. The adjustable range is from 100 MHz to
200 MHz. Auto sets the PCIe clock frequency to standard 100 MHz. (Default: Auto)

HT Link Frequency

Allows you to manually set the frequency for the HT Link between the CPU and chipset.

Auto

BIOS will automatically adjust the HT Link Frequency. (Default)

200 MHz~2 GHz

Sets HT Link Frequency to 200 MHz~2 GHz.

Set Memory Clock

Determines whether to manually set the memory clock. Auto  lets BIOS automatically set the
memory clock as required. Manual allows the memory clock control item below to be configurable.
(Default: Auto)

Memory Clock

This option is configurable only when Set Memory Clock is set to Manual.

x4.00

Sets Memory Clock to x4.00.

x5.33

Sets Memory Clock to x5.33.

x6.66

Sets Memory Clock to x6.66.

x8.00

Sets Memory Clock to x8.00.
