4 |

Chapter 1: Introduction

1�3

Specifications

Specifications

CPU Support

Socket AM4 support AMD® Ryzen™ 3rd Gen (Matisse/ Renoir) and Ryzen™ 4th Gen
(Vermeer/ Future) processors

Support for future AMD® Ryzen processors with BIOS update
* Please refer to www.biostar.com.tw for CPU support list.

Chipset

AMD® B550

Memory

4th Gen AMD Ryzen Processors (

Vermeer CPUs/ Future

 APUs):

Supports Dual Channel DDR4 4400+(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/ 2667/ 2400/ 2133

3rd Gen AMD Ryzen Processors (Matisse CPUs):

Supports Dual Channel DDR4 4400+(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/ 3200/ 2933/ 2667/ 2400/ 2133
3rd Gen AMD Ryzen with Radeon Graphics Processors (Renoir APUs):
Supports Dual Channel DDR4 4933+(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4000(OC)/ 3800(OC)/ 3600(OC)/
3200/ 2933/ 2667/ 2400/ 2133
4 x DDR4 DIMM Memory Slot, Max. Supports up to 128 GB Memory
Each DIMM supports

 non-ECC and ECC Un-buffered

8/ 16/ 32 GB DDR4 module

* Please refer to www.biostar.com.tw for Memory support list.

Storage

-- Total supports 2x M.2 socket and 4 x SATA III (6Gb/s) ports

4x SATA III Connector (6Gb/s) : Supports AHCI & RAID 0, 1, 10

1x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA):

Supports M.2 Type 2242/ 2260/ 2280 SSD module

Supports PCI-E 4.0 x4 (64Gb/s)/ 3.0 x4 (32Gb/s) - NVMe/ AHCI & SATA

 III (6.0Gb/s)

 SSD

1x M.2 (M Key) Socket (M2_PCIEG3_32G_SATA):

Supports M.2 Type 2242/ 2260/ 2280 SSD module

Supports PCI-E 3.0 x4 (32Gb/s) - NVMe/ AHCI & SATA

 III (6.0Gb/s)

 SSD

* M.2 (M Key) Socket (M2_PCIEG4_64G_SATA) : The bandwidth is depended on CPU. Supports

PCI-E 4.0 x4 (64Gb/s) speed, which depends only on Ryzen 3rd Gen Matisse and 4th Gen

Vermeer CPUs.

LAN

Realtek RTL8111H

10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability

Audio Codec

ALC897

7.1 Channels, High Definition Audio, Hi-Fi (Front)

USB

6x USB 3.2 (Gen1) port (4 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)

Expansion Slots

1x PCIe 4.0/ 3.0 x16 Slot (PCIEG4X16):
Supports PCIe 3.0 x16/ 4.0 x16 mode with AMD® Ryzen™ processors.

Supports PCIe 3.0 x16 mode AMD® Ryzen™ with Radeon Vega Graphics processors.

1x PCIe 3.0 x16 Slot (PCIEG3X4) : Supports x4 mode
1x PCIe 3.0 x1 Slot (PCIEG3X1)

* According to different CPUs will have different speeds.
* PCIe 4.0 speed only for AMD® Ryzen™ 3rd Gen Matisse and 4th Gen Vermeer CPUs.

* When using PCIe x1 slot (PCIEG3X1), PCIe x16 slot (PCIEG3X4) will be adjusted to x2 lanes.

Rear I/Os

B550MX/E PRO:
2x WIFI Antenna Port

1x PS/2

Keyboard /

Mouse

1x DVI-D Port
1x VGA Port

1x HDMI Port

1x LAN port

4x

USB 3.2 (Gen1)

 Port

2x

USB 2.0

 Port

3x Audio Jack

B550MH/E PRO:
2x WIFI Antenna Port

1x PS/2

Keyboard /

Mouse

1x VGA Port

1x HDMI Port

1x LAN port

4x

USB 3.2 (Gen1)

 Port

2x

USB 2.0

 Port

3x Audio Jack

»

Continued on Next Page
