Operation

Operation

General operations

Touch screen

Due to the touch screen, you can fulfill most

functions not only by pressing buttons but also
by touching the options you desired.

Turn on/off the power

Press PWR/SRC button on the RC or SEL

button on the panel to turn on the unit. When on,
press and hold this button to turn off the unit.

Mute

Press MUTE/LOUD button on the panel,

MUTE button on the RC or

 icon on the

screen to cut the sound. Pressing again or
adjusting volume will release muting.

Adjust the volume

Press VOL+/- buttons on the RC or rotate

VOL knob on the panel to increase or decrease
the volume level. The adjustable range of
volume is 0 to 42.

Source selection

•  Method 1: Press PWR/SRC button on the

RC or SEL button on the panel repeatedly to
cycle through available sources.

•  Method 2: Open the Source Menu by

touching the mode icon in the top left corner
of the TFT or by pressing MENU button on the
panel, and then touch the option you need.
Touch MORE icon to switch between the 1st
and 2nd menu pages.

  When some devices are not ready, the

corresponding mode is in grey and it cannot be
selected.

Panel tilt

•  Press and hold TILT button on the panel

or OPEN/CLOSE/P.ANGLE button on the RC,
then press it repeatedly to adjust the tilt angle of
the front panel.

•  Press TILT button on the panel or OPEN/

CLOSE/P.ANGLE button on the RC, to open
the front panel.

Calibration

Press and hold for several seconds “2“

digit button and BAND button on the RC
simultaneously to enter the calibration mode.
Touch the cross symbol in the place where it
will move after each pressing. After you press
it for the 5th time in the center of the screen,
“Calibration succeeded“ will be displayed.

  Calibration is required when some

malfunction of touch screen occurs.

AUX in jack

AUX-in jack on the front panel is intended

for connecting an external audio equipment. If
connection is made correctly, the audio signal
from the external source will be translated
through the acoustics of the head unit. This
enables to adjust the volume and quality of the
sounding.

Loudness

Press and hold MUTE/LOUD button on the

front panel or LOUD/EQ button on the RC to
switch on or off the bass emphasizing function.

System setup

In the 2nd page of the Source Menu, touch

SYSTEM icon to enter the System setup menu.
Or press and hold EQ/SYS button on the panel
or SYS button on the RC to enter the System
setup menu. In the bottom part of the screen
6 setup pages are available: Screen, Sound,
Clock, Saver, Others and Def. Touch the
needed icon to enter the corresponding page.
