Operation

Remote controller (RC)

1. MUTE button
2. PWR/SRC button
3. Digit buttons
4. AUDIO button
5. MENU button
6. LOUD/EQ button
7. BAND button
8. RPOG button
9. PREV/NEXT buttons
10. RDM button
11. SLOW button
12. TITLE button
13. ZOOM button
14. SUB-T button
15. SETUP button
16. OPEN/CLOSE/P.ANGLE button
17. VOL+/- buttons
18. PBC/AST button

19. DISP button
20. SYS button
21. F.REV/F.FWD buttons
22. Cursor ( / / / ) buttons
23. D.ANGLE button
24. STOP button
25. PLAY/PAUSE button
26. A-B button
27. REPEAT button
28. P/N button
29. ST button

Changing the battery

When the range of the operation of the

card RC becomes short or no functions while
operating, replace the battery with a new
lithium battery. Make sure the battery polarity
replacement is correct.

1. Open the back cover of the RC.
2. Insert the button-type battery with the

stamped (+) mark facing upward.

3. Close the back cover.

  •  Store the battery where children

cannot reach. If a child accidentally swallows
the battery, consult a doctor immediately.

•  Do not recharge, short, disassemble or

heat the battery or dispose it in a fire.

•  Do not expose or bring into contact the

battery with other metallic materials. Doing this
may cause the battery to give off heat, crack or
start a fire.

•  When throwing away or saving the battery,

wrap it in tape and insulate; otherwise, the
battery may give off heat, crack or start a fire.

•  The RC can operate within a distance of 3~5

m and the angle range of 30

0

 to the IR sensor.

1

2

3

5

6

7

4

8

10

9

11

26

12

27

14

29

15

16

17

18

20

19

21

23
24

22

25

13

28
