11

Operation

the screen will tilt up or down. There are 4
steps for tilting (ANGLE 0-4).

Reset the unit

Operating the unit for the first time or after

replacing the car battery, you must reset the
unit. Press reset button on the unit with a
pointed object (such as a ballpoint pen) to set
the unit to initial state.

  When some errors occur on the display,

you can also press reset button to resume to
normal, and it will erase the clock setting and
some memorized functions.

TFT display on/off

When the unit is on, press  /TFT OFF

button on the panel to switch off the display.
When the display is off, the video out signal will
be available so that the connected monitor will
show the screen of the unit. Press this button
again to resume the image.

Mode selection

•  Press repeatedly MOD button on the panel

or MODE button on the RC to select among
Radio, USB, Memory Card, auxiliary input
(AUX), TV, Bluetooth and HDMI operation
modes. Modes of operation are indicated on
the display. Memory card and USB modes are
not available unless a memory card or USB
device is connected.

Audio parameter setting

Press SELECT button on the panel or

SEL button on the RC repeatedly to select a
parameter: VOL (volume) => BASS (bass) =>
TRE (treble) => BAL (balance) => FAD (fader).
Rotate VOLUME knob on the panel or pressing
V+/V- buttons on the RC to adjust each mode:

•  Volume: from 0 to 39;
•  Bass/Treble: from -7 to 7;
•  Balance: L7 (left) to R7 (right);
•  Fader: from R7 (rear) to F7 (front);

Additional audio settings

You can adjust other audio settings like

preset equalizer, loudness or subwoofer ON/
OFF by tapping the “EQ” icon on the main
menu, or on the control menu of other audio/
video play modes.

EQ: POP/ROCK/CLASSIC/OFF equalizer

modes;

•  Loudness: select ON or OFF. Activating

this feature will enhance bass and treble
frequencies when listening to music at low
volumes.

  When equalizer is in any mode except

OFF, bass and treble are not adjustable.

AUX input

AUX-in jacks on the front panel and on the

back as part of the AV harness (red=right,
white=left) are intended for connecting external
audio equipment. If connection is made
correctly, the audio signal from the external
source will be translated through the acoustics
of the head unit. This enables to adjust volume
and quality of sounding. For example, you can
connect an MP3-player to listen to tracks using
the car acoustic system.

System setup

Enter the setup menu in the home screen

by tapping the “SETTING” icon on the main
menu. Tap the items you would like to set. You
can adjust audio, date and time, language,
calibration, etc.

Radio operation

Band select

In Radio mode press the BAND button

onscreen to choose among the five radio
bands - three FM Bands (FM1, FM2, and
FM3) and two AM Bands (AM1, and AM2).
Each of the five bands can store up to six
preset stations, for a total of 30 preset memory
stations.
