10

Operation

Remote controller (RC)

1

2

3

4

5

6

7

8

9

11

10

12

13

14
15

16

17

18

1. MODE button
2.   button
3.

 button

4. OK button/Cursor buttons
5. AUDIO button
6. BND/TYPE button
7. APS/RPT button
8. Number buttons
9. CLK/OSD button
10. MUTE button
11.

 button

12. V+ button
13. SEL button
14. V- button
15. SUB-T button
16.

/

 buttons

17. GOTO button
18. RATIO button

Changing the battery

1. Press the catch and at the same time pull

out the battery tray.

2. Insert 1 lithium battery, type CR 2025 3 V

with (+) mark facing up. Insert the battery tray
into the remote control.

•  Store the battery where children cannot

reach. If a child accidentally swallows the
battery, consult a doctor immediately.

•  Do not recharge, short, disassemble or

heat the battery or dispose it in a fire.

•  Do not expose or bring into contact the

battery with other metallic materials. Doing this
may cause the battery to give off heat, crack or
start a fire.

•  When throwing away or saving the battery,

wrap it in tape and insulate; otherwise, the
battery may give off heat, crack or start a fire.

•  Please direct the Remote controller to the

IR sensor of the front panel.

General operations

Touch screen

The touch screen enables you to carry out

most functions not only by pressing buttons but
also by touching the options you need.

Turning the unit on/off

Press  /TFT OFF button on the panel or

button on the RC to turn the unit on. Press and
hold the button to turn the unit off.

Sliding out the monitor

Press the TILT button so that the monitor

will slide out automatically and the main GUI
display will show up. Press the TILT button
again so that the screen will go back in the
chassis.

  Please do not adjust the monitor tilt

manually, otherwise it can get damaged

Angle of the screen

Press the UP/DOWN arrow buttons so that
