18.

EN

Electric air conditioner

portable type

Dehumidifying operation

Ensure the unit is plugged in and power is
available. The OPERATION indicator on the
display panel of the indoor unit illuminates.
1. Press the MODE button to select DRY mode.
2. Press the TEMP button to set the desired
temperature. The temperature can be set
within a range of 17 C(62 F)~ 30 C in 1 C(2 F)
increments.
3. Press the ON/OFF button to start the air
conditioner.

NOTE:

In the Dehumidifying mode, you can not switch the fan
speed. It has already been automatically controlled.

Swing operation(on some models)

Use the SWING button to adjust the Up/Down

airflow direction .
1. When press the button once and quickly, the
air flow direction setting feature of the louver is

activated. The moving angle of the louver is
6o for each press. Keep pressing the button to
move the louver to the desired position.

NOTE:

On some models press it to initiate the Auto
swing feature only.
2. If keep pressing the SWING button without
releasing for 2 more seconds, the auto swing
feature of the louver is activated. The horizontal
louver would swing up/down automatically.
Press it again to stop.

NOTE:

When the louver swing or move to a position which

would affect the cooling and heating effect of the air

conditioner, it would automatically change the swing/
moving direction.

Timer operation

Press the TIMER ON button can set the auto-on time
of the unit. And press the TIMER OFF button can set

the auto-off time of the unit.

To set the Auto-on time.

1. Press the TIMER ON button. The remote
controller shows TIMER ON, the last Auto-on
setting time and the signal “h” will be shown on the
LCD display area. Now it is ready to reset the Auto-on
time to START the operation.
2. Push the TIMER ON button again to set desired Au-
to-on time. Each time you press the button, the time
increases in 30 minutes increments, up to 10 hours,
then at 1 hour increments up to 24 hours.

3. After setting the TIMER ON ,there will be a onehalf

second delay before the remote controller trans-

mits the signal to the air conditioner. Then, after

LED DISPlAY

RESET LOCK

TIMER OFF

TIMER ON

FAN SPEED

FAN
HIGH
MED
LOW

AUTO
COOL
DRY
HEAT

TEMP

ECONOMY

SWING

MODE

SET TEMPERATURE (  C)

LED DISPlAY

RESET LOCK

TIMER OFF

TIMER ON

FAN SPEED

FAN
HIGH
MED
LOW

AUTO
COOL
DRY
HEAT

TEMP

ECONOMY

SWING

MODE

SET TEMPERATURE (  C)

2

3

1

1

Fig.15.

Fig.16.
