12.

EN

Electric air conditioner

portable type

Operating Instructions
COOL operation

Press the “MODE” button until the “COOL” indicator light comes on.

Press the ADJUST buttons “▲” or “ “ to select your desired room temperature. The temperature

can be set within a range of 17OC-30OC/62OF-88OF (or 86OF).
Press the “FAN” button to choose the fan speed.

DRY operation

Press the “MODE” button until the “DRY” indicator light comes on. Under this mode, you cannot
select a fan speed or adjust the temperature. Keep windows and doors closed for the best dehu-

midifying effect. Do not put the duct to window.

AUTO operation

When you set the air conditioner in AUTO mode, it will automatically select cooling, fan only oper-
ation depending on what temperature you have selected and the room temperature.
The air conditioner will control room temperature automatically round the temperature point set
by you.
Under AUTO mode, you can not select the fan speed.

FAN operation

Press the “MODE” button until the “FAN “ indicator light comes on.
Press the “FAN” button to choose the fan speed. The temperature cannot be adjusted.
Do not put the duct to window.

TIMER operation

When the unit is on, first press the Timer button, the TIMER OFF indicator light illuminates. It

indicates the Auto Stop program is initiated.Press the Timer button again,the TIMER ON indicator
light illuminates. It indcates the Auto  Start program is initiated.

When the unit is off, first press the Timer button, the TIMER ON indicator light illuminates. It indi

-

cates the Auto Start program is initiated. When the unit.Press the Timer button again,the TIMER
OFF indicator light illuminates. It indcates the Auto Stop program is initiated.
Press or hold the UP or DOWN button to change the Auto time by 0.5 hour increments, up to 10
hours, then at 1 hour increments up to 24 hours. The control will count down the time remaining
until start.
The selected time will register in 5 seconds and the system will automatically revert back to
display the previous temperature setting.
Turning the unit ON or OFF at any time or adjusting the timer setting to 0.0 will cancel the Auto
Start/Stop timed program.
When the malfunction (E1 or E2) occurs, the Auto Start/Stop timed program will also be
cancelled.

SLEEP/ECO operation

Press this button, the selected temperature will increase(cooling) or decrease(heating) by
1OC/2OF(or 1OF) 30 minutes.The temperature will then increase (cooling) or decrease (heating)

by another 1OC/2OF(or 1 OF) after an additional 30 minutes. This new temperature will be main

-

tained for 7 hours before it returns to the originally selected temperature. This ends the Sleep/
Eco mode and the unit will continue to operate as originally programmed.

NOTE:

Under AUTO mode, both the AUTO mode and the actual operation
mode indicator lights illuminate.
