G

B

19

2.

LAYOUT (

Fig. 1, 2, 3)

1.

Shroud

2.

Pressure vessel

3.  Intake air filter

4.

Supporting rubber foot

5.  Quick-lock coupling (regulated compressed air)

6.  Pressure gauge (for reading the preset pressure by

means of the pressure regulator)

7.

Pressure regulator

8.

I/O

 switch (ON/OFF)

9.

Transportation handle

10.

Safety valve

11.

Drain valve

12. Pressure gauge (for reading the tank pressure)

3.  SCOPE OF USE

The compressor is designed for generating compressed

air for tools operated by compressed air.
Please note that our equipment has not been designed for use

in  commercial,  trade  or  industrial  applications.  Our  warranty

will be voided if the machine is used in commercial, trade or

industrial businesses or for equivalent purposes.
The machine is to be used only for its prescribed purpose.

Any other use is deemed to be a case of misuse. The user/

operator and not the manufacturer will be liable for any

damage or injuries of any kind caused as a result of this.

4.

POINTS TO NOTE WHEN SETTING

UP THE COMPRESSOR

● Examine the machine for signs of transit damage. Report

any damage immediately to the company which delivered

the compressor.

●

The compressor should be set up near the working

consumer.

● Avoid long air lines and long supply lines (extensions).

● Make sure the intake air is dry and dust-free.

● Do not set up the compressor in damp or wet rooms.

● The compressor may only be used in suitable rooms (with

good ventilation and an ambient temperature from +5°C to

+40°C). There must be no dust, acids, vapors, explosive

gases or inflammable gases in the room.

● The compressor is designed to be used in dry rooms. It

is prohibited to use the compressor in areas where work

is conducted with sprayed water.

5.

ASSEMBLY AND STARTING

  Warning!

You must fully assemble the appliance before using it

for the first time.

5.1

Fitting the air filter (ref. 3)

Remove the transportation stop with a screwdriver or

similar  and  screw  the  air  filter  (ref.  3)  securely  to  the

equipment (Fig. 3a-3b).

If  supplied,  insert  the  suction  tube  inside  the  filter  cover

(Fig. 3c).

5.2

Assembling the quick coupler (if not

already assembled)

Tighten  the  quick  coupler  for  regulated  pressure  to  the

coupling on the outlet as shown in figures 5a and 5b.

5.3

Voltage

The  compressor  is  equipped  with  a  mains  cable  with

shock-proof  plug.  Insert  the  plug  of  the  electric  cable

in  a  socket  of  suitable  shape,  voltage  and  frequency

complying  with  current  regulations.  Before  you  use  the

machine, make sure that the mains voltage complies with

the  specifications  on  the  rating  plate.  Make  sure  that  the

ON/OFF switch is

not

 in the

I

 (

ON

) position. Long supply

cables,  extensions,  cable  reels  etc.  cause  a  drop  in

voltage and can impede motor start-up. In the case of low

temperatures below +5°C, motor start-up is jeopardized as

a result of stiffness.

5.3.1  Connection of the mains plug (electrical

information for the BS plug)

  Important!

The  wires  in  the  mains  lead  fitted  to  this  product  are

coloured in accordance with the code shown in fig. 10.

●

The 3 pin plug must comply to BS1363/A.

●

Fuse must comply to BS1362.

If  for  any  reason  the  13  amp  plug  fitted  to  this  product

requires replacement it must be wired in accordance with

the following instruction:

Do not connect the brown (live) or blue (neutral) to the

earth pin marked ‘E’

  on the 3 pin plug.

Connect the Blue wire to the terminal marked Neutral (N).

Connect  the  Brown  wire  to  the  terminal  marked  Live  (L).

Connect the Yellow & Green wire to the terminal marked

Earth (E). Ensure that the outer insulation is gripped by the

cord grip and that the wires are not trapped when replacing

the plug cover. The mains lead on this product is fitted with

a 13 amp (BS1363/A) plug. A 13 amp (BS1362) fuse must

be fitted in the plug.

If in doubt consult a qualified electrician.

There are no user serviceable parts inside this product

except  those  referred  to  in  the  manual.  Always  refer

servicing  to  qualified  service  personnel.  Never  remove

●

The compressor's performance is guaranteed for

operation between 0 and 1000 meters above the sea level.
