COMPRAG Screw air compressor A-Series

LCD Status Display

COMPRAG SCREW
AIR COMPRESSOR

The display screen will show as below after power on:

After 5 seconds, the menu will switch main compressor parameters:

TEMP: --°C

SYS STOP C01

Current temperature of the oil-air mixture
Current compressor working status

Press enter    .

PRES:--.-bar

SYS STOP C01

Current pressure at compressor air outlet
Current compressor working status

Select the menu options using the up    and down   buttons and enter  :

RUN PARAMETERS

Includes current values (available for viewing)

USAGE PARAM

Includes operating settings of the main parameters (available for

viewing, changes password-protected)

FACTORY PARAM

For servicing mode (view with password). Modification only possible

by manufacturer

ADJUST. PARAM

Basic settings and maintenance hour counter (view and change with

password). Modification only possible by distributor’s technical staff

Run parameters

These parameters apply only to the display of the current settings of the product.

RUN PARAMETERS
MOTOR M1 A-0.0

Current consumption per phase

B-0.0 C-0.0

TOTAL RUN TIME

Total operating hours (loaded and idle run time)

---h--m

Current value

TOTAL LOAD TIME

Total load hours

---h--m

Current value

THIS RUN TIME

Operating hours since last switched on (loaded and idle run time)

---h--m

Current value

THIS LOAD TIME

Load hours since last switched on

---h--m

Current value

OIL FILTER TIME

Operating time since last service

0110h

Current value
