Dear Coffee Connoisseur,

Congratulations on purchasing this fully
automatic espresso machine from Siemens.

These instructions describe various models
with different features.
Please also note the enclosed quick
reference guide. It can be kept in the
special storage compartment

25

 until it is

needed.

Overview

Figures A, B, C, D a

nd

 E

1

  Power on/off switch

O

 /

I

  2

a

 button

3

°C

 button (temperature / child-proof lock)

4

  Selection buttons

<

>

  5

  Display

a)

 Status line

b)

 Selection line

c)

 Navigation line

6

Rotary knob for display settings

7

  Info menu button

j

8

start

button (drinks / programmes)

9

   Coffee outlet, height-adjustable and

swivelling

10

   Milk frother, height-adjustable

(milk / hot water)

a)

 Upper part

b)

 Lower part

c)

 Tube

d)

 Milk pipe

11

  Removable water tank

12

  Lid for water tank

13

   Storage compartments

(measuring spoon and milk frother
accessories)

14

   Measuring spoon

(insertion aid for water filter)

15

  Bean container

16

  Aroma cover

17

  Selector for grind setting

18

  Illuminated ring

 19

  Cup warming

 20

   Button for cup warming function,

illuminated

 21

   Drawer

(ground coffee / cleaning tablet)

 22

  Door to brewing unit

23

  Door opener

24

  Brewing unit

a)

 Sliding button

b)

 Lock

 25

   Storage compartment for quick

reference guide

 26

  Cover of storage compartment

 27

  Drip tray panel

 28

  Drip tray for coffee outlet

 29

  Grate for coffee outlet

 30

  Drip tray for milk frother

 31

  Grate for milk frother

 32

  Coffee grounds container

 33

  Cable storage compartment

 34

  Milk container (insulated)

 35

  Water filter
