18

en

●

Separate the milk tube from the suction

pipe�

●

Clean the individual parts with washing-

up liquid and a soft cloth�

●

Rinse all parts with clean water and dry

them�

F

The upper and lower parts of the milk

system

4b

, the milk tube

4c

 and the

suction pipe

4d

 can also be cleaned

in a dishwasher�

●

Reassemble the individual parts�

●

Place the milk system

4b

 back in the

appliance from the front, making sure it is

straight�

●

Replace the cover

4a

�

Cleaning the brewing unit (Figure G)

F

See also the Quick reference guide

in the storage compartment

16

�

In addition to the automatic cleaning

programme, the brewing unit

14

 should be

removed regularly for cleaning�

●

Use the main switch

J

1

 to switch the

appliance completely off�

●

Open the door

13

to the brewing unit�

●

Slide the red latch

14a

 on the brewing

unit

14

 all the way to the left�

●

Press the eject lever

15

 right down� The

brewing unit will be released�

●

Take hold of the brewing unit

14

 by the

recessed grips and carefully remove it�

F

Important:

 Clean it without using

washing-up liquid and do not put it in

the dishwasher�

●

Remove the cover

14b

 and thoroughly

clean the brewing unit

14

 under running

water�

●

Thoroughly clean the strainer of the

brewing unit under the water jet�

●

Thoroughly clean the inside of the appli-

ance with a moist cloth, removing any

coffee residues�

●

Allow the brewing unit

14

 and the inside

of the appliance to dry�

●

Replace the cover

14b

 on the brewing

unit and then push the brewing unit

14

back into the appliance until it latches into

place�

●

Press the eject lever

15

 right up�

●

Slide the red latch

14a

 all the way to the

right and close the door

13

�
