5

TES515.. | 7/2014

en

Controls

Power on/off switch O / I

The power switch

O / I

(9) is used to switch

the appliance on or to switch it off fully

(power supply off).

Important:

 Before switching off, run the

cleaning programme or use the

k

off /

i

button (13) to switch off.

a

 button

Press the

a

 button (11) to prepare

two cups of the selected drink at the

same time. The button can be activated

for drinks without milk and without the

aromaDouble Shot

 function.

k

 off /

i

 button

When the

k

off /

i

 button (13) is pressed

briefly, the appliance rinses and switches

off. Pressing and holding down the

k

off /

i

button (13) displays the user settings or

starts the descaling and cleaning function.

l

 /

m

 button

Press the button

l

 /

m

 (12) to generate

steam for preparing milk froth.This button is

also used to dispense hot water.

start button

Press the

start

 button (10) to begin drink

preparation or to start a service programme.

Press the

start

 button (10) again during

drink preparation to cut the dispensing

process short.

Overview

(see overview images

A, B, C, D

and

 E

at

the beginning of this instruction manual)

1

Bean container

2

Aroma cover

3

Selector for grind setting

4

Drawer (ground coffee/cleaning tablet)

5

Brewing unit (

Fig. E

)

a)

Brewing unit

b)

Door

c)

Storage compartment for

quick reference guide

d)

Eject lever for brewing unit

e)

Lock

f)

Cover

6

Milk frother (

Fig. C

) removable

a)

Outlet

b)

Connection (milk tube)

c)

Milk tube

d)

Upper part

e)

Air nozzle

7

Coffee outlet, height-adjustable

8

Drip tray (

Fig. D

)

a)

Drip tray panel

b)

Coffee grounds container

c)

Drip tray for coffee outlet

d)

Grate for coffee outlet

e)

Float

9

Power on/off switch

O / I

10  start

button

11

a

 button

12

l

 /

m

 button

13

k

off /

i

 button

14

“Coffee strength” rotary knob

15

“Drink selection” rotary knob

16

Display

17

Removable water tank

18

Lid for water tank

19

Measuring spoon

(insertion aid for water filter)

20

Storage compartment for

measuring spoon

21

Power cable with storage compartment
