NOTICE*

The stainless steel doors are provided with a high-quality surface

coating  and  must  not  be  treated  using  the  accompanying  care

product.

Otherwise the surface coating will be affected.

u

Wipe the coated door surfaces using a soft, clean cloth only.

u

Apply  a  stainless  steel  cleaner  only  to  the  stainless  steel

side walls evenly, wiping with the grain. Subsequent cleaning

becomes easier as a result.

u

Wipe side walls with a paint finish using a soft, clean cloth

only.

u

Remove all transit supports.

u

Dispose of packaging material (see 4.5) .

NOTICE

Risk of damage due to condensate!

u

Do not install the appliance directly alongside a further refrig-

erator/freezer.

u

Align  the  appliance  so  that  it

stands firmly and on a level by

applying  the  accompanying

spanner  to  the  adjustable-

height feet (A) and using a spirit

level.

u

Then support the door: Extend

the  adjustable  foot  at  the  turn

hinge  (B)  until  it  rests  on  the

floor  and  then  make  a  further

90° turn.

If the appliance is installed in a very damp environment, conden-

sate may form on the outside of the appliance.

u

Always see to good ventilation at the installation site.

4.5 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

EPS moulded parts

-

polythene bags and sheets

-

polypropylene straps

u

Take the packaging material to an official collecting point.

4.6 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The type of current (alternating current) and voltage at the instal-

lation site have to conform with the data on the type plate  (see

Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.
It must be easily accessible so that the appliance can

be quickly disconnected from the supply in an emer-

gency.

u

Check the electrical connection.

u

Clean the appliance  (see 6.2) .

u

Plug in the power plug.

4.7 Switching on the appliance

Note

u

To switch on the entire appliance it is necessary only to switch

on  the  freezer  compartment.  In  so  doing,  the  refrigerator

compartment is automatically switched on as well.

Put the appliance into operation about 2 hours before first loading

food to be frozen.

4.7.1 Switching on the freezer compartment

u

PressOn/Off button, freezer compartment

 Fig. 3 (8).

w

The appliance is switched on. The refrigerator compartment

temperature  display  indicates  the  set  temperature.  The

freezer  compartment  temperature  display  and  the  alarm

button flash until the temperature is sufficiently low.

4.7.2 Switching on the refrigerator compart-

ment

Note

u

When the refrigerator compartment is switched on, the freezer

compartment is automatically switched on as well.

u

Press On/Off button, refrigerator compartment

 Fig. 3 (1).

w

The interior light is on when the door is open.

w

The  temperature  display  shines.  Refrigerator  compartment

and freezer compartment are switched on.

5 Control

5.1 Door alarm

If the door is open longer then 60 s, the audible alarm sounds.
The  audible  alarm  is  automatically  silenced  when  the  door  is

closed.

5.1.1 Muting the door alarm

The  audible  alarm  can  be  muted  when  the  door  is  open.  The

sound switch-off function is active as long as the door is left open.

u

Press alarm button

 Fig. 3 (7).

w

The door alarm is silenced.

5.2 Temperature alarm

The audible alarm sounds if the freezer temperature is not cold

enough.
The alarm button flashes at the same time.

The cause of the temperature being too high may be:

-

warm fresh food was placed inside

-

too much warm ambient air flowed in when rearranging and

removing food

-

power failure for some time

-

the appliance is faulty

The  audible  alarm  is  automatically  silenced,  the  alarm  button

Fig.  3  (7)  goes  out  and  the  temperature  display  stops  flashing

when the temperature is sufficiently cold again.

Control

7
