5.4.7 Drawers

Fig. 12

u

Pull out drawers

 (1) to the limit.

u

Then raise the drawer at the back, pull it forwards and lift it.

w

In the case of the bottom drawer, the drawer lock is additionally

released and the drawer can be removed.

u

Disengage  drawer  cover

  (2)  with  humidity  controller  of

removed drawers by lifting and draw it forwards for removal.

Fig. 13

u

To  insert  drawer  cover

  (2):  Insert  mouldings  of  the  drawer

cover into the rear holders from underneath and snap into the

holder at the front.

u

Place  drawers

 (1) on the rails and slide them all the way in

until the drawer audibly snaps into place.

w

In the case of the bottom drawer, the drawer lock additionally

engages and the vegetable drawer sits firmly on the telescopic

rails.

5.5 Freezer compartment

You can store frozen food, make ice cubes and freeze fresh food

in the freezer compartment.

5.5.1 Freezing food

The maximum weight of fresh food which can be frozen within 24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".
The  maximum  load  for  an  individual  drawer  and  the  plate  is

25 kg frozen food.

CAUTION

Risk of injury due to broken glass!

Bottles and cans containing drinks may burst when being frozen.

This applies particularly to sparkling drinks.

u

Do not freeze bottles and cans containing drinks!

In order that the food is rapidly frozen through to the core, do not

exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg

- Meat up to 2.5 kg

u

Pack  the  food  in  portions  in  freezer  bags,  reusable  plastic,

metal or aluminium containers.

5.5.2 Thawing food

- in the refrigerator compartment

- at room temperature

- in a microwave oven

- in a conventional or fan oven

u

Food  once  thawed  should  be  re-frozen  only  in  exceptional

cases.

5.5.3 Setting the temperature

Temperature setting to be recommended: -18 °C
The  temperature  can  be  changed  continuously.  Once  the

-32 °C setting is reached, it starts again with -15 °C.

u

To  access  temperature  adjustment:  press  setting  button,

freezer compartment

 Fig. 3 (5) once.

u

Press  the  setting  button,  freezer  compartment

  Fig.  3  (5)  the

number of times needed until the required temperature shines

in the LED display.

Note

u

Long pressing of the setting button sets a slightly colder value

within  a  small  temperature  range  (e.g.:  between  -15  °C  and

-18 °C) but it is not visible in the display.

5.5.4 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
The maximum amount of fresh food which can be frozen in 24 h

is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".  This  amount  varies  according  to  the  model  and  climate

rating.
Freezing with SuperFrost
You do not have to activate SuperFrost in the following cases:
- when placing frozen food in the freezer

- when freezing up to about 2 kg fresh food daily

u

Briefly press the SuperFrost button

 Fig. 3 (6).

w

The SuperFrost button shines.

w

The  freezer  temperature  drops,  the  appliance  operates  with

the maximum refrigerating capacity.

In case of a small amount of food to be frozen:

u

wait about 6 h.

u

Place the fresh food in the top drawers.

In case of the maximum amount of food to be frozen (see type

plate):

u

wait about 24 h.

u

Place food in the drawers.

w

SuperFrost is automatically deactivated after about 65 h.

w

The SuperFrost button is dark.

w

The  appliance  continues  to  operate  in  the  energy-saving,

normal mode.

5.5.5 Drawers

Note

The energy consumption increases and the cooling performance

decreases if there is insufficient ventilation.

For appliances with NoFrost:

u

Leave the bottom drawer in the appliance!

u

Always keep the air slits of the fan free at the rear wall!

u

To store frozen food directly on the shelves: pull the drawer

forwards and lift it out.

5.5.6 Shelves

u

To remove the shelf: lift up at the front and

pull out.

u

To put the shelf back: simply push in as far

as it will go.

Control

10
