5.5.7 VarioSpace

Apart from being able to remove the

drawers,  you  can  also  remove  the

shelves,  creating  space  for  large

items  of  frozen  food.  Poultry,  meat,

large pieces of game and high bakery

products can be frozen in one piece

and prepared.

u

The maximum load of frozen food

for an individual drawer or shelf is

25 kg.

5.5.8 Information system

Fig. 14

(1) Ready-made meals, ice

cream

(4) Sausages, bread

(2) Pork, fish

(5) Game, mushrooms

(3) Fruit, vegetables

(6) Poultry, beef/veal

The figures indicate the storage time in months for several types

of frozen food in each case. Storage times given are guide times.

5.5.9 Cold storage accumulators

The  cold  storage  accumulators  prevent  the  temperature  from

rising too fast in the event of power failure.
Using cold storage accumulators

u

Place the cold storage accumula-

tors  in  the  top  freezer  compart-

ment to save space.

u

Place  the  frozen  cold  storage

accumulators  on  the  frozen  food

in  the  upper  front  area  of  the

freezer compartment.

6 Maintenance

6.1 Defrosting with NoFrost

The NoFrost system automatically defrosts the appliance.
Refrigerator compartment:
The defrost water evaporates due to the compressor heat.

u

Regularly  clean  the  drain  opening  to  allow  the  water  to  flow

away  (see 6.2) .

Freezer compartment:
The  moisture  condenses  on  the  evaporator,  is  periodically

defrosted and evaporates.

u

The appliance does not have to be manually defrosted.

6.2 Cleaning the appliance

Before cleaning:

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

NOTICE

Incorrect cleaning damages the appliance!

u

Do not use cleaning agents in concentrated form.

u

Do not use any scouring or abrasive sponges or steel wool.

u

Do  not  use  any  cleaning  agents  containing  sand,  chloride,

chemicals or acid.

u

Do not use chemical solvents.

u

Do not damage or remove the type plate on the inside of the

appliance. It is important for the customer service.

u

Do not pull off, bend or damage cables or other components.

u

Do  not  allow  any  cleaning  water  to  enter  the  drain  channel,

ventilation grille or electrical parts.

u

Empty the appliance.

u

Pull out the plug.

- Use  soft  cleaning  cloths  and  a  multi-purpose

cleaning agent with neutral pH value.

- Only use food compatible cleaning and care agents

on the inside of the appliance.

u

Regularly clean ventilation grilles.

w

Dust deposits increase energy consumption.

Outside surfaces and interior:

u

Clean the plastic surfaces, outside and inside, by hand using

lukewarm water and a little washing-up liquid.

NOTICE*

The stainless steel doors are provided with a high-quality surface

coating  and  must  not  be  treated  using  the  accompanying  care

product.

Otherwise the surface coating will be affected.

u

Wipe the coated door surfaces using a soft, clean cloth only.

In case of stubborn dirt, use a little water or a neutral cleaning

agent. A microfibre cloth can be optionally used.

u

If the stainless steel side walls are dirty, clean them using

a commercially available stainless steel cleaning agent. Then

evenly apply the accompanying stainless steel care product,

making strokes in the direction of the grain.

u

Wipe side walls with a paint finish using a soft, clean cloth

only.  In  case  of  stubborn  dirt,  use  a  little  water  or  a  neutral

cleaning agent. A microfibre cloth can be optionally used.

Do  not  apply  stainless  steel  cleaning  agent  to  glass  or  plastic

surfaces to prevent them from being scratched. Darker areas at

the beginning and quite an intensive colour of the stainless steel

surface are normal.*

u

To  clean  the  drain  opening:  remove

any  deposits  with  a  fine  instrument,

e.g. a cotton bud.

Items of equipment:

u

Clean items of equipment by hand with lukewarm water and

a little washing-up liquid.

u

For cleaning, remove the support rails for the half-sized glass

shelves.

u

To dismantle the shelves: remove the

trims and side parts.

u

Take apart the door rack as illustrated.

After cleaning:

u

Wipe dry the appliance and items of equipment.

u

Connect the appliance and switch it on again.

u

Switch on SuperFrost (see 5.5.4) .

When the temperature is sufficiently cold:

Maintenance

11
