Please keep these instructions in a safe place and pass them

on to any subsequent owners.

-

Special-purpose lamps (incandescent lamps, LEDs, fluores-

cent tubes) in the appliance serve to illuminate the appliance

interior and are not suited for room illumination.

Fire hazard:

-

The  refrigerant  R  600a  is  environmentally  friendly  but  flam-

mable. Escaping refrigerant may ignite.

•

Do not damage the refrigerant circuit pipes.

•

Do not allow naked flames or ignition sources to enter the

appliance.

•

Do  not  use  any  electrical  appliances  in  the  interior  (e.g.

steam cleaners, heaters, ice cream maker etc.).

•

If refrigerant escapes: eliminate naked flames or sources

of ignition from the vicinity. Pull out the power plug. Venti-

late the area well. Notify customer service.

-

Do not store explosives or sprays using combustible propel-

lants such as butane, propane, pentane, etc. in the appliance.

Respective spray cans can be identified by reference to the

contents  printed  on  the  can  or  by  a  flame  symbol.  Gases

possibly escaping may ignite due to electrical components.

-

Do not place any burning candles, lamps or other items with

naked flames on or in the appliance.

-

Only store high-percentage alcohol in tightly sealed, upright

containers. Alcohol possibly escaping may ignite due to elec-

trical components.

Danger of tipping and falling:

-

Do not misuse the plinth, drawers, doors etc. as a step or for

support. This applies particularly to children.

Danger of food poisoning:

-

Do not consume food which has been stored too long.

Danger of frostbite, numbness and pain:

-

Avoid lasting skin contact with cold surfaces or refrigerated/

frozen food or take protective steps, e.g. wear gloves. Do not

consume ice cream, water ice or ice cubes immediately and

do not consume them too cold.

Please  observe  the  specific  information  in  the  other

sections:

DANGER

identifies a situation involving direct

danger which, if not obviated, may

result in death or severe bodily injury.

WARNING

identifies a dangerous situation

which, if not obviated, may result in

death or severe bodily injury.

CAUTION

identifies a dangerous situation

which, if not obviated, may result in

minor or medium bodily injury.

NOTICE

identifies a dangerous situation

which, if not obviated, may result in

damage to property.

Note

identifies useful information and tips.

3 Controls and displays

3.1 Operating and control elements

Fig. 3

(1) On/Off button, refriger-

ator compartment

(5) Setting button, freezer

compartment

(2) Setting button, refriger-

ator compartment

(6) SuperFrost button

(3) Refrigerator compart-

ment temperature

display

(7) Alarm button

(4) Freezer compartment

temperature display

(8) On/Off button, freezer

compartment

3.2 Temperature display

The following are displayed in normal operation:

-

the set freezing temperature

-

the set cooling temperature

The freezer compartment temperature display flashes:

-

the temperature setting is being changed

-

after switch-on the temperature is not yet cold enough

-

the temperature has risen several degrees

4 Putting into operation

4.1 Changing over the door hinges

You can change over the door hinges if necessary.

Ensure that the following tools are to hand:

q

Torx 25

q

Torx 15

q

Screwdriver

q

Cordless screwdriver, if necessary

q

Second person for fitting work, if needed

4.1.1 Detaching the upper door

Note

u

Remove  any  food  from  the  door  racks  before  removing  the

door, so that no food falls out.

Fig. 4

u

Close the upper door.

u

Pull off the cover

 Fig. 4 (1) forwards and upwards.

u

Lift off the cover

 Fig. 4 (2)

CAUTION

Risk of injury if the door tips!

u

Take good hold of the door.

u

Set down the door carefully.

u

Unscrew the upper turn hinge

 Fig. 4 (3)(2 Torx 25) Fig. 4 (4)

and raise it for removal.

u

Lift up the upper door and set it aside.
