14

 | English

1 609 92A 3WR | (10.8.17)

Bosch Power Tools



Router bits or other accessories must fit exactly in the
tool holder (collet) of your machine.

Routing bits that do

not fit precisely in the tool holder of the machine rotate ir-
regularly, vibrate heavily and can lead to loss of control.



Apply the machine to the workpiece only when
switched on.

Otherwise there is danger of kickback when

the cutting tool jams in the workpiece.



Never cut over metal objects, nails or screws.

The rout-

er bit can become damaged and lead to increased vibra-
tions.



Use appropriate detectors to determine if utility lines
are hidden in the work area or call the local utility com-
pany for assistance.

Contact with electric lines can lead

to fire and electric shock. Damaging a gas line can lead to
explosion. Penetrating a water line causes property dam-
age.



Do not use blunt or damaged router bits.

Blunt or dam-

aged router bits cause increased friction, can become
jammed and lead to imbalance.



Always wait until the machine has come to a complete
stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.



Do not open the battery.

Danger of short-circuiting.

Protect the battery against heat, e. g., against
continuous intense sunlight, fire, water, and
moisture.

Danger of explosion.



In case of damage and improper use of the battery,
vapours may be emitted. Ventilate the area and seek
medical help in case of complaints.

The vapours can irri-

tate the respiratory system.



Use the battery only in conjunction with your Bosch
power tool.

This measure alone protects the battery

against dangerous overload.



The battery can be damaged by pointed objects such as
nails or screwdrivers or by force applied externally.

An

internal short circuit can occur and the battery can burn,
smoke, explode or overheat.

Product Description and
Specifications

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The power tool is intended for milling edges and profiles in
wood, plastic and non-metallic lightweight materials while
resting firmly on the workpiece.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Battery pack *

2

Battery unlocking button *

3

Temperature control/overload protection indicator

4

Battery charge-control indicator

5

On/Off switch

6

Marking arrow for spindle lock

7

Spindle lock lever

8

Depth-of-cut coarse adjustment button

9

Tightening nut with collet

10

Thumbwheel for depth-of-cut fine adjustment

11

Depth-of-cut adjuster fixing screw

12

Base plate

13

Handle

14

Depth-of-cut adjuster locking wheel

15

Collet

16

Tool holder

17

Router bit *

18

Open-end spanner (17 mm)

19

Smooth guide column

* Accessories shown or described are not part of the standard
delivery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 60745-2-17.
Typically the A-weighted sound pressure level of the product
is 73 dB(A). Uncertainty K = 3 dB.
The noise level when working can exceed 80 dB(A).

Wear hearing protection!

Palm router

GKF 12V-8

Article number

3 601 FB0 0..

Rated voltage

V=

12

No-load speed

min

-1

13 000

Tool holder

mm
mm

inch

6
8

¼

Max. diameter of milling cutter

mm

36

Weight according to
EPTA-Procedure 01:2014

kg

1.3 – 1.5

1)

Permitted ambient temperature
– during  charging
– during operation

2)

 and during

storage

° C

° C

0 ... + 45

– 20 ... + 50

Recommended batteries

GBA 12 V...

GBA 10,8 V...

Recommended chargers

GAL 12.. CV

AL 11.. CV

1) depending on the battery pack being used

2) limited performance at temperatures < 0 ° C
