ENGLISH

en

11

The cutter continues running after the machine

has been switched off. Wait for the standstill of

the cutter.

Reverse/replace planer knives (17) that have

turned blunt (see page 3, fig. B)

1. Turn the drive belt (14) until the planer knife is

accessible.

2. Fastening screws (15) (16)

must be loosened

(not unscrewed)

 with key.

3. Using a piece of wood, push the planer knife (17)

out from the side (see arrow in fig.).

4. Insert reversed/new planer knife (17). (order no.

see chapter 10. accessories).

5. Centrally align the planer knife (17): It protrudes

the cutter (18) on the right and left by 1 mm

respectively.

6. Firmly tighten (10-15 Nm) the fastening screws

(15) with key (16) - the central fastening screw

first.

7. Also reverse/replace the second planer knife.

ONLY IF NEEDED:

Adjust the holder of the planer knife (19) (see

page 3, fig. C)

The holder of the planer knife (19) comes correctly

adjusted from the factory. In case it got misaligned,

adjust it as follows:
1. Turn the drive belt (14) until the planer knife is

accessible.

2. Fastening screws (15) (16)

must be loosened

with key.

3. Remove mounting plate (20).

4. Remove planer knife (17) and planer knife

holder (19) .

5.

Loosen

 the screws (22).

6. Position the planer knife holder (19) (as shown)

on the setting gauge (21):

Align in such a way that the planer knife holder

(19) makes contact with spot A and at the same

time the planer knife (17) makes contact with

spot B at the setting gauge (21). See figure!

7. Tighten (1,4 - 2,2 Nm) both screws (22).

8. Insert planer knife holder (19) and planer knife

(17) (as shown) in the cutter (18) and align

centrally.

9. Position the mounting plate (20) (as shown) and

firmly tighten (10-15 Nm) the fastening screws

(15) with a key (16) - the central fastening screw

first.

10.If required, also adjust the second planer knife

holder (19).

Pull the plug out of the socket before making

any adjustments, changing tools, carrying out

maintenance or cleaning.

Danger of injury from sharp edges of the

planer knives.
The cutter continues running after the machine

has been switched off. Wait for the standstill of

the cutter.

Clogged ejection nozzle

Use a suitable tool, e.g. a piece of wood to

clean a clogged ejection nozzle (10). Do not

reach into the ejection nozzle (10).

Clean the machine regularly.

 Remove chip

ejection adapter (13) and clean e.g. with a cloth.

Vacuum clean the ventilation louvres on the motor.

Use only genuine Metabo - accessories.
Use only accessories that fulfil the requirements

and specifications listed in these operating

instructions.

A Carbide reversible planer knife

Order no.: 6.30282 (2 pieces)

Order no.: 6.30272 (10 pieces)

For a complete range of accessories, see

www.metabo.com or the catalogue.

Repairs to electrical tools must ONLY be

carried out by qualified electricians!

The mains cable must only be replaced by Metabo

or an authorised customer service workshop.
The drive belt cable must only be replaced by

Metabo or an authorised customer service

workshop.
Contact your local Metabo representative if you

have Metabo power tools requiring repairs. See

www.metabo.com for addresses.
You can download a list of spare parts from

www.metabo.com.

Observe national regulations on environmentally

compatible disposal and on the recycling of disused

machines, packaging and accessories.

Only for EU countries: never dispose of

power tools in your household waste! Used

power tools must be collected separately and

handed in for environmentally compatible recycling

in accordance with European Directive 2012/19/EU

on waste electrical and electronic equipment and its

implementation in national legal systems.

Explanatory notes on the specifications on page 3.

Subject to change in accordance with technical

progress.

U

= Voltage of battery pack

P

1

= Rated  input  power

P

2

= Power output

b

= Planing  width

t

= adjustable planing depth

f

max

= Largest rabbetting depth

l

= Length of the planer’s sole

n

0

= Idle  speed

n

1

= Speed at rated load

9. Troubleshooting, cleaning

10. Accessories

11. Repairs

12. Environmental Protection

13. Technical Data
