The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.

u

Hold the power tool firmly with both hands and make
sure you have a stable footing.

 The power tool can be

more securely guided with both hands.

Product Description and
Specifications

Read all the safety and general instructions.

Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.

Please observe the illustrations at the beginning of this oper-
ating manual.

Intended use

The power tool is intended for planing wood-based materials
such as beams and boards while resting firmly on the work-
piece. It is also suitable for chamfering edges and for rebat-
ing.

Product features

The numbering of the product features refers to the diagram
of the power tool on the graphics page.

(1)

Cutting depth scale

(2)

Knob for setting the cutting depth (insulated gripping
surface)

(3)

Chip ejector (GHO 26-82 D: Either right or left)

(4)

Lock-off button for on/off switch

(5)

On/off switch

(6)

Changeover lever for chip ejector direction
(GHO 26-82 D)

(7)

Planer base plate

(8)

V-groove

(9)

Handle (insulated gripping surface)

(10)

Blade head

(11)

Clamping element for planer blade

(12)

Fastening screw for planer blade

(13)

HM/TC planer blade

(14)

Hex key

(15)

Extraction hose (dia. 35 mm)

A)

(16)

Chip/dust bag

A)

(17)

Parallel guide

(18)

Scale for rebate width

(19)

Locking nut for rebate width setting

(20)

Fastening screw for parallel/angle guide

(21)

Angle guide

A)

(22)

Locking nut for angle setting

(23)

Fastening screw for rebate depth guide

(24)

Rebate depth guide

A)

(25)

Parking rest

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical data

Planer

GHO 16-82

GHO 26-82 D

Article number

3 601 EA4 0..

3 601 EA4 3..

Rated power input

W

630

710

No-load speed

rpm

18,000

18,000

Cutting depth

mm

0–1.6

0–2.6

Rebate depth

mm

0–9

0–9

Max. planing width

mm

82

82

Weight according to EPTA-Procedure 01:2014

kg

3.4

3.4

Protection class

 / II

 / II

The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-
specific models.

Noise/vibration information

Noise emission values determined according to

EN 62841-2-14

.

Typically the A-weighted noise level of the power tool is:
Sound pressure level

84

 dB(A); sound power level

95

dB(A). Uncertainty K =

3

 dB.

Wear hearing protection

Total vibration values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 62841-2-14

:

a

h

 =

8

 m/s

2

, K =

1.5

 m/s

2

,

The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
