14

★

Tool does not operate

-  kickback brake is activated -> pull hand guard S

2

back in position

$

a

-  no power supply -> check power supply (power cable,

circuit breakers, fuses)

-  plug not connected -> connect plug

-  extension cord damaged -> replace extension cord

★ Tool operates intermittently

-  on/of switch defective -> contact dealer/service

station

-  internal wiring defective -> contact dealer/service

station

-  extension cord damaged -> replace extension cord

★ Dry chain

-  no oil in reservoir -> reill oil

-  vent in oil reservoir cap clogged -> clean cap

-  oil passage clogged -> clean oil passage outlet

★

Brake does not stop chain

-  kickback brake/run-down brake defective -> contact

dealer/service station

★

Chain/chain bar overheats

-  no oil in reservoir -> reill oil

-  vent in oil reservoir cap clogged -> clean cap

-  oil passage clogged -> clean oil passage outlet

-  chain is overtensioned -> adjust chain tension

-  dull chain -> sharpen chain or replace

★ Tool vibrates abnormally

-  chain tension too loose -> adjust chain tension

-  dull chain -> sharpen chain or replace

-  chain worn out -> replace chain

-  chain teeth are facing in the wrong direction ->

reassemble with chain in correct direction

ENVIRONmENT

•

Do not dispose of electric tools, accessories and

packaging together with household waste material

(only for EU countries)

-  in observance of European Directive 2012/19/EC on

waste of electric and electronic equipment and its

implementation in accordance with national law,

electric tools that have reached the end of their life

must be collected separately and returned to an

environmentally compatible recycling facility

-  symbol

8

 will remind you of this when the need for

disposing occurs

DEClARATION OF CONFORmITY

•  We declare under our sole responsibility that the product

described under “Technical data” is in conformity with the

following standards or standardization documents: EN

60745, EN 61000, EN 55014, in accordance with the

provisions of the directives 2004/108/EC, 2006/42/EC,

2000/14/EC, 2011/65/EU

•

Technical file at

: SKIL Europe BV (PT-SEU/ENG1),

4825 BD Breda, NL

¹ÊÁÂÆιƼ½ÊÇǾ¼½Æ

ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿

ÍÊÇȽƓˁ˅ʿ˂ ʽ¼¹Ɠ

Ĺ¾ ÁÂÿʹ¹¾

ÈÈÊÇιĹƹ¿½Ê

19.12.2013

NOISE/VIBRATION

•  Measured in accordance with EN 60745 the sound

pressure level of this tool is 87 dB(A) and the sound

power level 107 dB(A) (standard deviation: 3 dB), and the

vibration 4.7 m/s² (hand-arm method; uncertainty K = 1.5

m/s²)

•  Measured in accordance with 2000/14/EC (EN/ISO

3744) the guaranteed sound power level LWA is lower

than 110 dB(A) (conformity assessment procedure

according to Annex V)

•  The vibration emission level has been measured in

accordance with a standardised test given in EN 60745; it

may be used to compare one tool with another and as a

preliminary assessment of exposure to vibration when

using the tool for the applications mentioned

-  using the tool for diferent applications, or with diferent

or poorly maintained accessories, may signiicantly

increase

 the exposure level

-  the times when the tool is switched of or when it is

running but not actually doing the job, may signiicantly

reduce

 the exposure level

!  protect yourself against the effects of vibration

by maintaining the tool and its accessories,

keeping your hands warm, and organizing your

work patterns

Tronçonneuse à chaîne

0780

INTRODUCTION

•  L’outil électrique est conçu pour scier le bois, comme par

ex. les poutres en bois, les planches, les branches, les

tronçons ainsi que pour abattre des arbres; il peut être

utilisé pour des coupes dans et contre le sens des ibres

du bois

•  Cet outil n’est conçu pour un usage professionnel

•  Vériiez que le conditionnement contient toutes les

pièces présentées dans le schéma

2

•  Lorsque des pièces manquent ou sont endommagées,

veuillez contacter votre distributeur

•  Lisez attentivement ce manuel d’instruction avant

d’utiliser l’outil et conservez-le pour pouvoir vous y

référer ultérieurement

3

•  Prêtez attention aux consignes de sécurité et aux

avertissements; ne pas suivre ces instructions peut

entraîner des graves blessures
