16 ENGLISH

—  The sharpening angle of 30° must be the same on

all cutters. Different cutter angles cause the chain

to run roughly and unevenly, accelerate wear, and

lead to chain breaks.

—  Use a suitable round file so that the proper sharp

-

ening angle is kept against the teeth.

•

Chain blade 90PX : 55°

•

Chain blade 91PX : 55°

File and file guiding

—  Use a special round file (optional accessory) for

saw chains to sharpen the chain. Normal round

files are not suitable.

—  Diameter of the round file for each saw chain is as

follows:
•

Chain blade 90PX : 4.5 mm (3/16″)

•

Chain blade 91PX : 4.0 mm (5/32″)

—  The file should only engage the cutter on the for

-

ward stroke. Lift the file off the cutter on the return

stroke.

—  Sharpen the shortest cutter first. Then the length

of this shortest cutter becomes the standard for all

other cutters on the saw chain.

—  Guide the file as shown in the figure.

►

Fig.35:

1.

 File

2.

 Saw chain

—  The file can be guided more easily if a file holder

(optional accessory) is employed. The file holder

has markings for the correct sharpening angle of

30° (align the markings parallel to the saw chain)

and limits the depth of penetration (to 4/5 of the

file diameter).

►

Fig.36:

1.

 File holder

—  After sharpening the chain, check the height of the

depth gauge using the chain gauge tool (optional

accessory).

►

Fig.37

—  Remove any projecting material, however small,

with a special flat file (optional accessory).

—  Round off the front of the depth gauge again.

Cleaning the guide bar

Chips and sawdust will build up in the guide bar groove.

They may clog the bar groove and impair the oil flow.

Clean out the chips and sawdust every time when you

sharpen or replace the saw chain.

►

Fig.38

Cleaning the sprocket cover

Chips and saw dust will accumulate inside of the

sprocket cover. Remove the sprocket cover and saw

chain from the tool then clean the chips and saw dust.

►

Fig.39

Cleaning the oil discharge hole

Small dust or particles may be built up in the oil dis-

charge hole during operation. These dust or particles

may impair the oil to flow and cause an insufficient

lubrication on the whole saw chain. When a poor chain

oil delivery occurs at the top of guide bar, clean the oil

discharge hole as follows.

1.

Remove the sprocket cover and saw chain from

the tool.

2.

Remove the small dust or particles using a slotted

screwdriver with a slender shaft or the like.

►

Fig.40:

1.

 Slotted screwdriver

2.

 Oil discharge hole

3.

Insert the battery cartridge into the tool. Pull the

switch trigger to flow built-up dust or particles off the oil

discharge hole by discharging chain oil.

4.

Remove the battery cartridge from the tool.

Reinstall the sprocket cover and saw chain on the tool.

Replacing the sprocket

CAUTION:

A worn sprocket will damage a

new saw chain. Have the sprocket replaced in this

case.

Before fitting a new saw chain, check the condition of

the sprocket.

►

Fig.41:

1.

 Sprocket

2.

 Areas to be worn out

Always fit a new locking ring when replacing the

sprocket.

►

Fig.42:

1.

 Locking ring

2.

 Sprocket

NOTICE:

Make sure that the sprocket is installed

as shown in the figure.

Storing the tool

1.

Clean the tool before storing. Remove any chips

and sawdust from the tool after removing the sprocket

cover.

2.

  After cleaning the tool, run it under no load to lubri

-

cate the saw chain and guide bar.

3.

Cover the guide bar with the guide bar cover.

4.

  Empty the oil tank.
