11 ENGLISH

Tips for maintaining maximum

battery life

1.

Charge the battery cartridge before completely

discharged. Always stop tool operation and

charge the battery cartridge when you notice

less tool power.

2.

Never recharge a fully charged battery car-

tridge. Overcharging shortens the battery

service life.

3.

Charge the battery cartridge with room tem-

perature at 10 °C - 40 °C (50 °F - 104 °F). Let

a hot battery cartridge cool down before

charging it.

4.

Charge the battery cartridge if you do not use

it for a long period (more than six months).

PARTS DESCRIPTION

►

Fig.2

1

Battery cartridge

2

Front hand guard

3

Guide bar

4

Saw chain

5

Lever

6

Adjusting dial

7

Check button

8

Capacity indicator

9

Main power lamp

10

Main power switch

11

Lock-off lever

12

Rear handle

13

Switch trigger

14

Front handle

15

Oil tank cap

16

Chain catcher

17

Adjusting screw (for oil pump)

18

Guide bar cover

FUNCTIONAL

DESCRIPTION

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

Installing or removing battery

cartridge

CAUTION:

Always switch off the tool before

installing or removing of the battery cartridge.

CAUTION:

Hold the tool and the battery car-

tridge firmly when installing or removing battery

cartridge.

 Failure to hold the tool and the battery

cartridge firmly may cause them to slip off your hands

and result in damage to the tool and battery cartridge

and a personal injury.

►

Fig.3:

1.

 Red indicator

2.

 Button

3.

 Battery cartridge

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip

it into place. Insert it all the way until it locks in place

with a little click. If you can see the red indicator on the

upper side of the button, it is not locked completely.

CAUTION:

Always install the battery cartridge

fully until the red indicator cannot be seen.

 If not,

it may accidentally fall out of the tool, causing injury to

you or someone around you.

CAUTION:

Do not install the battery cartridge

forcibly.

 If the cartridge does not slide in easily, it is

not being inserted correctly.

NOTE:

 The tool does not work with only one battery

cartridge.

NOTE:

 Pay attention to the position of your fin

-

gers when installing the battery. The button will be

depressed unintentionally.

Tool / battery protection system

The tool is equipped with a tool/battery protection sys-

tem. This system automatically cuts off power to the

motor to extend tool and battery life. The tool will auto-

matically stop during operation if the tool or battery is

placed under one of the following conditions.

Overload protection

When the tool is operated in a manner that causes it

to draw an abnormally high current, the tool automat-

ically stops and the main power lamp will blink. In this

situation, turn the tool off and stop the application that

caused the tool to become overloaded. Then turn the

tool on to restart.

Overheat protection

When the tool is overheated, the tool automatically

stops and the capacity indicator lamp will blink as illus-

trated. In this situation, let the tool cool down before

turning the tool on again.

Capacity indicator status

Status

On

Off

Blinking

Overheated.

Overdischarge protection

When the battery capacity becomes low, the tool stops

automatically. If the product does not operate even

when the switches are operated, remove the batteries

from the tool and charge the batteries.
