External Dust Extraction

For dust extraction, a vacuum hose (size
Ø 36 mm) can also be connected to the dust
ejector

21

.

The vacuum cleaner must be suitable for the ma-
terial being worked.
When vacuuming dry dust that is especially det-
rimental to health or carcinogenic, use a special
vacuum cleaner.

Changing the Tool (see figures D1

–

D4)

f

Before any work on the machine itself, pull
the mains plug.

f

When mounting the saw blade, wear protec-
tive gloves.

Danger of injury when touching

the saw blade.

Use only saw blades whose maximum permitted
speed is higher than the no-load speed of the
power tool.
Use only saw blades that correspond with the
characteristic data given in these operation in-
structions and that are tested and marked in ac-
cordance with EN 847-1.
Use only saw blades recommended by the tool
manufacturer, and suitable for sawing the mate-
rials to be cut.

Removing the Saw Blade

– Bring the power tool into the working posi-

tion.

– Turn the Allen screw

30

 with the Allen key

22

provided while at the same time pressing the
spindle lock

28

 until it engages.

– Hold the spindle lock

28

 pressed and un-

screw the Allen screw

30

 in clockwise direc-

tion (left-hand thread!).

– Remove the clamping flange

31

.

– Press lever

3

 and swing back the retracting

blade guard

5

 to the stop.

– Hold the retracting blade guard in this posi-

tion and remove the saw blade

17

.

– Slowly guide the retracting blade guard

downward again.

Mounting the Saw Blade

If required, clean all parts to be mounted prior
to assembly.
– Press lever

3

, swing back the retracting

blade guard

5

 to the stop and hold it in this

position.

– Place the new saw blade onto the interior

clamping flange

32

.

f

When mounting the saw blade, pay atten-
tion that the cutting direction of the teeth
(arrow direction on the saw blade) corre-
sponds with the direction of the arrow on
the blade guard!

– Slowly guide the retracting blade guard

downward again.

– Place on the clamping flange

31

 and the

screw

30

.

Press the spindle lock

28

 until it engages and

tighten the screw turning in anticlockwise di-
rection.

Operation

f

Before any work on the machine itself, pull
the mains plug.

Transport Safety (see figure E)

The transport safety-lock

24

 enables easier han-

dling of the machine when transporting to vari-
ous working locations.

Releasing the Machine (Working Position)

– Push the tool arm by the handle

1

 down a lit-

tle in order to relieve the transport safety-
lock

24

.

– Pull the transport safety-lock

24

 completely

outward.

– Guide the tool arm slowly upward.

Securing the Machine (Transport Position)

– Tighten clamping lever

25

 to lock the saw ta-

ble

11

.

– Press lever

3

 and at the same time, swing the

tool arm by handle

1

 toward the rear until the

transport safety-lock

24

 can be pushed com-

pletely inward.

The tool arm is now securely locked for trans-
port.
