26

 | English

1 609 929 U75 | (19.7.10)

Bosch Power Tools

Functional Description

Read all safety warnings and all in-
structions.

Failure to follow the

warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.

Intended Use

The power tool is intended as a stationary ma-
chine for making straight lengthways and cross-
ways cuts in wood. In this, mitre angles from
– 46 °  to +46 °  as well as bevel angles from 0 °  to
45 °  are possible.
The capacity of the power tool is designed for
sawing hardwood and softwood.
The power tool is not suitable for cutting alumin-
ium or other non-ferrous metals or alloys.

Product Features

The numbering of the components shown refers
to the representation of the power tool on the
graphic pages.

1

Handle

2

Laser warning label

3

Lever for releasing the tool arm

4

Blade guard

5

Retracting blade guard

6

Fence

7

Insert plate

8

Screws for insert plate

9

Handle for turning the saw table

10

Scale for mitre angle (horizontal)

11

Saw table

12

Mounting holes

13

Recessed grips

14

Material clamp

15

Scale for bevel angle (vertical)

16

Roller

17

Saw blade

18

Dust bag

19

On/Off switch

20

Laser switch (for marking of cutting line)

21

Sawdust ejector

22

Allen key (size 6 mm)

23

Clamping lever for various bevel angles
(vertical)

24

Transport safety-lock

25

Clamping lever for any mitre angle

26

Allen screws (6 mm) of the fence

27

Drill holes for material clamp

28

Spindle lock

29

Battery compartment

30

Allen screw (size 6 mm) for mounting of saw
blade

31

Clamping flange

32

Interior clamping flange

33

Wing bolt

34

Threaded rod

35

Angle indicator (horizontal)

36

Angle indicator (vertical)

Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.

Only for EC countries:

Do not dispose of power tools into household waste!
According the European Guideline 2002/96/EC for Waste Electrical and
Electronic Equipment and its implementation into national right, power
tools that are no longer usable must be collected separately and dis-
posed of in an environmentally correct manner.

Symbol

Meaning
