9

ENGLISH

TECHNICAL PASSPORT

Electric oven

Electrical connection

Â

The oven is manufactured to work

with  a  one-phase  alternating  current

(230V  1N~50  Hz)  and  is  equipped

with a 3 x 1,5 mm2 connection lead of

1.5  mm  length  with  a  plug  including  a

protection contact.

Â

A connection socket for electricity

supply should be equipped with a

protection pin and may not be located

above  the  cooker.  After  the  cooker  is

positioned,  it  is  necessary  to  make  the

connection socket accessible to the user.

Â

Before  connecting  the  oven  to

the socket, check if:

B

the fuse and electricity supply

are able to withstand the cooker load,

B

the electricity supply is

equipped  with  an  efficacious  ground

system which meets the requirements

of current standards and provisions,

B

the plug is within easy reach.

Important!

If  the  fixed  power  supply  cable

is  damaged,  it  should  be  replaced  at

the manufacturer or at an authorized

servicing outlet, or by a qualified person

to avoid danger.

O P E RAT I O N

Before using the appliance for

the first time

Â

Remove  packaging,  clean  the

interior of the oven,

Â

Take  out  and  wash  the  oven

accessories with warm water and a little

washing-up liquid,

Â

Turn on the ventilation in the

room or open a window,

Â

Heat  up  the  oven  (to  a

temperature of 250°C for approximately

30  minutes),  remove  any  stains  and

wipe the interior carefully. (See section:

Using the control panel)

Important!

To clean the oven chamber use only

warm water and a small amount of

washing-up liquid.

The oven is equipped with a

retractable  knobs.  In  order  to  select  a

function do the following:

1.  Gently  press  and  release  a  knob

which will pop out,

2. Turn the oven functions selection

knob to the desired function.

Symbols  printed  around  the  knob

indicate available oven functions.

Important!

The oven features touch control

panel and display. To activate each touch

sensor, touch the glass above the sensor

(indicated  by  a  pictogram).  An  acoustic

signal will be heard. (See section: Using

the control panel).

Touch sensor surfaces must be kept

clean.

Some models are equipped with a

backlit oven door handle. For additional

information on oven accessories

depending  on  the  model,  please  see

section Features and components.

Oven  handle  backlight  is  turned  on

during operation and acts as oven cavity

residual heat indicator, i.e. it turns off

when the temperature inside the oven

cavity  drops  below  50°C. The  backlight

is  on  above  50°C  and  light  intensity

reflects  the  temperature,  i.e.  the  higher

the temperature inside the oven cavity

the higher the backlight intensity.
