Note: The oven goes into On / Off mode 2 seconds after the selection, in order to allow the user to cancel
any accidental selection simply by pressing again the key

 (4).

After 1 minute in Program_00 (LIGHT) position, the oven will turn off automatically.


Timer mode

The timer does not interact with the program settings and is always available, whichever the operating status
is. Press and release the key

 (5)1 time, as described in the table above. Correct the value by using the

keys  “+” (3) or “-“ (6). The maximum available time is 23h:59m. The value is edited on a 1 minute basis.
To confirm the edited value, press the key

 (5). Otherwise, the value is accepted 4 seconds after the last

keyboard action, and the display goes back to the previous operating mode.
When the selected time is finished, an acoustic signal will be heard and the icon   will be flashing. Press the
keys  “+” (3) or “-“ (6) or the key

 (5), or the key

 (4) to stop the signal and to turn off the icon  .

Manual cooking mode

Turn on the oven and select a cooking program by means of the keys  “+” (7) or “-“ (8): the oven gives a
default temperature.
The temperature shown on the display can be changed using the keys  “+” (1) or “-“ (2) on the left of the
control panel, with variations of 5°C, from a minimum of 50°C up to a maximum of 250°C.
The °C symbol flashes upon reaching the desired temperature. The oven will start cooking 4 second after.


Semi-automatic cooking mode: time of cooking

Turn on the oven, select a cooking program, check the temperature on the display and then press the key

 (5) 2 times.

The timer display shows “dur”. Edit the value by means of the keys  “+” (3) or “-“ (6). The value is edited on a
1 minute basis. The maximum available time is 10h:00m. The value is accepted 4 seconds after the last key
touch.


Fully automatic delayed cooking mode

Turn on the oven, select a cooking program, check the temperature on the display, select a cooking time and
press

 (5). The timer display shows “End”.

Edit the value by means of the keys  “+” (3) or “-“ (6). The value is edited on a 1 minute basis. The maximum
available time is 23h:59m. The value is accepted 4 seconds after the last key touch, and the oven goes to
“Wait to start” mode.
The oven will turn off immediately, and it will turn on later for the specified cooking time until the End of
Cooking time is reached.
During this phase, the Cooking Program Display shows, in low intensity light, the selected cooking function,
and the temperature display shows the selected temperature. Both are further changeable. The square
around the cooking function is switched off.
The Preheating Bar graph is fully off to indicate that the oven is currently not heating.


End of cooking mode

When the set end of cooking is reached, the oven turns off automatically, and an acoustic signal is heard.
The Cooking Program and Temperature displays are turned off, the Timer display shows the current time
with both “A”  and

 symbols flashing.

Press any of the keys  “+” (3) or “-“ (6) or the key

 (5) to unlock the oven: it will immediately go to normal

Manual Cooking Mode. By pressing the key

 (4) the oven will turn off.

Cooking Program selection

Press and release the keys  “+” (7) or “-“ (8): the Timer display will show the currently selected Program
Number or “Pr00” if no program has been selected.
The Cooking Program display will show the Oven Cavity border symbol flashing to indicate that the program
is being edited.
Choose the desired program by means of the keys  “+” (7) or “-“ (8) which will scroll the list between “Pr 00”
and “Pr 10” (or “ Etc”). See the Cooking Program Table below.
The selection of the program is accepted 4 seconds  after and the oevn starts functioning immediately.





32
