13

Bar

The smaller the tip radius the lower the chance of kick-
back.

Chain

A chain is made up of a number of links, which are
available in standard and low-kickback versions.

IMPORTANT! No saw chain design elimi-
nates the danger of kickback.

WARNING! Any contact with a rotating saw
chain can cause extremely serious injuries.

SHARPENING YOUR CHAIN AND ADJUST-
ING DEPTH GAUGE SETTING

WARNING! Always wear gloves, when work-
ing with the chain, in order to protect your
hands from injury.

General information on sharpening cutting teeth
•  Never use a blunt chain. When the chain is blunt

you have to exert more pressure to force the bar
through the wood and the chips will be very small. If
the chain is very blunt it will produce wood powder
and no chips or shavings.

•  A sharp chain eats its way through the wood and

produces long, thick chips or shavings.

•  The cutting part of the chain is called the cutter and

consists of a cutting tooth and the depth gauge.

  The cutters cutting depth is determined by the dif-

ference in height between the two (depth gauge set-
ting).

When you sharpen a cutting tooth there are four impor-
tant factors to remember.
1 Filing angle
2 Cutting angle
3 File position
4 Round

fi

 le diameter

It is very dif

fi

 cult to sharpen a chain correctly without the

right equipment. We recommend that you use our

fi

 le

gauge. This will help you obtain the maximum kickback
reduction and cutting performance from your chain.

WARNING! Departure from the sharpening
instructions considerably increases the risk
of kickback.

•  Check that the chain is correctly tensioned. A slack

chain will move sideways, making it more dif

fi

 cult to

sharpen correctly.

• Always

fi

 le cutting teeth from the inside face. Re-

duce the pressure on the return stroke. File all the
teeth on one side

fi

 rst, then turn the chain saw over

and

fi

 le the teeth on the other side.

•  File all the teeth to the same length. When the length

of the cutting teeth is reduced to 4 mm (0.16") the
chain is worn out and should be replaced.

WARNING! The risk of kickback is increased
if the depth gauge setting is too large!

WARNING! Overexposure to vibration can
lead to circulatory damage or nerve damage
in people who have impaired circulation.

Contact your doctor if you experience symptoms of
overexposure to vibration. Such symptoms include
numbness, loss of feeling, tingling, pricking, pain, loss
of strength, changes in skin colour or condition. These
symptoms normally appear in the

fi

 ngers, hands or

wrists. These symptoms may be increased in cold tem-
peratures.

Stop switch

Use the stop switch to switch off the engine.

Muf

fl

 er

The muf

fl

 er is designed to reduce noise levels and to

direct exhaust fumes away from the user.

WARNING! The exhaust fumes from the en-
gine are hot and may contain sparks which
can start a

fi

 re. Never start the machine in-

doors or near combustible material!

CAUTION! The muf

fl

 er gets very hot during

and after use. This also applies during idling.
Be aware of the

fi

 re hazard, especially when

working near

fl

 ammable substances and/or vapours.

WARNING! Never use a saw without a muf-

fl

 er, or with a damaged muf

fl

 er.  A  damaged

muf

fl

 er may substantially increase the noise

level and the

fi

 re hazard. Keep

fi

 re

fi

 ghting  equipment

handy. If a spark arrestor screen is required in your ar-
ea, never use the saw without or with a broken spark
arrestor screen.

CUTTING EQUIPMENT GENERAL RULES

•  Only use cutting equipment recommended by us!
•  Keep the chain’s cutting teeth properly sharpened!
•  Maintain the correct depth gauge setting! Follow our

instructions and use the recommended depth gauge
clearance. Too large a clearance increases the risk
of kickback.

•  Keep the chain properly tensioned! If the chain is

slack it is more likely to jump off and lead to in-
creased wear on the bar, chain and drive sprocket.

•  Keep cutting equipment well lubricated and properly

maintained! A poorly lubricated chain is more likely
to break and lead to increased wear on the bar,
chain and drive sprocket.

CUTTING EQUIPMENT DESIGNED
TO REDUCE KICKBACK

The only way to avoid kickback is to make sure that the
kickback zone of the bar never touches anything.
By using cutting equipment with ”built-in” kickback
reduction and keeping the chain sharp and wellmain-
tained you can reduce the effects of kickback.
