ENGLISH

 MAINTENANCE

Before cleaning or carrying out maintenance operations, disconnect the
equipment by removing the plug or switching off the main switch.
Do not use detergents containing abrasive, acidic or corrosive substances
or abrasive cloths.

Regular maintenance guarantees proper operation and performance over time.
Special attention is to be paid to the

metal anti-grease filters

: frequent cleaning of the

filters and their supports ensures that no flammable grease is accumulated.

CLEANING OF EXTERNAL SURFACES

You are advised to clean the external surfaces of the hood

at least once every 15 days

to

prevent oily substances and grease from sticking to them. To clean the brushed stainless
steel hood, the Manufacturer recommends using "Magic Steel" wipes.
Alternatively

and for all the other types of surfaces

, it can be cleaned using a damp cloth,

slightly moistened with mild, liquid detergent or denatured alcohol.
Complete cleaning by rinsing well and drying with soft cloths.

Do not use too much moisture or water around the push button control
panel and lighting devices in order to prevent humidity from reaching
electronic parts.

The glass panels can only be cleaned with specific, non-corrosive or non-abrasive deter-
gents using a soft cloth.
The Manufacturer declines all responsibility for failure to comply with these instructions.

CLEANING OF INTERNAL SURFACES

Do not clean electrical parts, or parts related to the motor inside the hood,
with liquids or solvents.

For the internal metal parts, see the previous paragraph.

METAL ANTI-GREASE FILTERS

It is advised to

frequently

 wash the metal filters (

at least once a month

) leaving them to

soak in boiling water and cleaning solution for 1 hour, taking care not to bend them.
Do not use corrosive, acid or alkaline detergents.
Rinse them well and wait for them to be completely dry before reassembling them.
Washing in a dishwasher is permitted, however, it may cause the filter material to darken: to
reduce the possibility of this problem from happening, use low-temperature washes (55°C
max.).
To extract and insert the metal anti-grease filters see the assembly instructions.

HOOD MOVEMENT SETUP

Press button

 for 10 seconds

When SETUP is started, all LEDs light up

The hood moves slowly upwards
until it reaches the upper limit
switch

The hood moves downwards
until it reaches the lower limit
switch.
If you want to set the hood stop
before it reaches the lower limit
switch, which represents the
maximum lowering, press + or

- on the button panel or

 or

 or

 USING THE RADIO CONTROL

WARNINGS!:

Place the hood away from sources of electromagnetic
waves (e.g. microwave ovens), which could interfere

with the radio control and with the hood electronics. The maxi-
mum operating distance is 5 metres, that may vary according to
the presence of electromagnetic interferences.
Radio control operated at 433.92MHz.
The radio control consists of two parts:
- the receiver built into the hood;
- the transmitter shown here in the figure.

DESCRIPTION OF TRANSMITTING COMMANDS

Press
briefly

UP

Motor switch-on and speed increase from 1 to 4. Speed 4 is
only active for a few minutes.

Pressure
prolonged

Lifting the hood

Activated only with the fan not working.
Stop:
- when the upper microswitch is reached

- pressing the

 or

 or

.

Press
briefly

DOWN

Decremento velocità e spegnimento motore

Pressure
prolonged

Lowering the hood

Activated only with the fan not working.
Stop:
- when the lower microswitch is reached

- pressing the

 or

 or

.

Press
briefly

Accensione / spegnimento luce

Pressure
prolonged

Cambio tonalità della luce da 2700K a 5600K

Press
briefly

TIMER:

Autospegnimento del motore dopo 15min.

The function is deactivated if the

 or

 button is pres-

sed.

RADIO CONTROL CODE CHANGE

With only one radio control, go directly to point 2.
With several radio controls in the same room, a new code can be created by following the
procedure below.

Disconnect the power to the hood before starting the procedure.

1) - CREATE A NEW CODE

The procedure is to be carried out on the radio control.

•

 Press

LIGHT

 and TIMER

 simultaneously until the display starts flashing.

•

 Press

DOWN

 on the radio control: saving is confirmed by three brief flashes of the

display. The new code cancels and replaces the previous default code.

Reconnect the hood to the electrical power supply, making sure that the
lights and motor are off.

2A) - ASSOCIATING THE RADIO CONTROL WITH THE HOOD
           USING THE ELECTRONIC PUSHBUT TON PANEL


press TIMER (

)

on the hood pushbutton panel

 for 2 seconds:

the red LED lights up.
press any key on the radio control within 10 seconds. .

RESTORING DEFAULT CODE

the procedure is to be carried out if the hood is disposed of, sold or transferred.

Disconnect the power to the hood before starting the procedure.

•

 Press

UP

 and DOWN

 simultaneously on the radio control for more than 5 sec-

onds: reset is confirmed by three brief flashes of the display.

•

  Reconnect the hood to the electrical power supply.

•

  Proceed with associating the hood and the radio control, as described in point 2.
