noise.

Additional Installation Specifications:

Use only the fixing screws supplied with the product for
installation or, if not supplied, purchase the correct screws
type.
Use the correct length for the screws which are identified in
the Installation Guide.
In case of doubt, consult an authorised service assistance
centre or similar qualified person.

WARNING!

Failure to install the screws or fixing device in

accordance with these instructions may result in electrical
hazards.

Use

The hood is designed to be used either for exhausting or filter
version.

Ducting version

The hood is equipped with a top air outlet

B

 for discharge of

fumes to the outside (exhaust pipe and pipe fixing clamps not
provided).

Attention! If the hood is supplied with carbon filter, then it
must be removed.

Filter version

Should it not be possible to discharge cooking fumes and
vapour to the outside, the hood can be used in the

filter

version

, fitting an activated carbon filter and the deflector

F

on the support (bracket)

G

, fumes and vapours are recycled

through the top grille

H

 by means of an exhaust pipe

connected to the top air outlet

B

 and the connection ring

mounted on the deflector

F

 (exhaust pipe and pipe fixing

clamps not provided).

Attention! If the hood is not supplied with carbon filter,
then it must be ordered and mounted.

The models with no suction motor only operate in ducting
mode, and must be connected to an external suction device
(not supplied).
The connecting instructions are supplied with the peripheral
suction unit.

Installation

The minimum distance between the supporting surface for the
cooking equipment on the hob and the lowest part of the
range hood must be not less than 50cm from electric cookers
and 65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a
greater distance, this must be adhered to.

  Electrical connection

The mains power supply must correspond to the rating
indicated on the plate situated inside the hood. If provided with
a plug connect the hood to a socket in compliance with current
regulations and positioned in an accessible area, after
installation. If it not fitted with a plug (direct mains connection)
or if the plug is not located in an accessible area, after
installation,  apply a double pole switch in accordance with
standards which assures the complete disconnection of the
mains under conditions relating to over-current category III, in

accordance with installation instructions.

Warning!

 Before re-connecting the hood circuit to the mains

supply and checking the efficient function, always check that
the mains cable is correctly assembled.
The hood is provided with a special power cable ; if the cable
is damaged, request a new one from Technical Service.

Mounting

Before beginning installation:

•

Check that the product purchased is of a suitable size for
the chosen installation area.

•  To facilitate installation, remove the fat filters and the

other parts allowed and described here, dismantle and
mount it.

To remove see also the relative paragraphs.

•

Remove the active carbon (*) filter/s if supplied (see also
relative paragraph). This/these is/are to be mounted only
if you want lo use the hood in the filtering version.

•  Check (for transport reasons) that there is no other

supplied material inside the hood (e.g. packets with
screws (*), guarantees (*), etc.), eventually removing
them and keeping them.

•

If possible, disconnect and move freestanding or slide-in
range from cabinet opening to provide easier access to
rear wall/ceiling. Otherwise put a thick, protective
covering over countertop, cooktop or range to protect
from damage and debris. Select a flat surface for
assembling the unit. Cover that surface with a protective
covering and place all canopy hood parts and hardware
in it.

•  Disconnect the hood during electrical connection, by

turning the home mains switch off.

•

In addition check whether near the installation area of the
hood (in the area accessible also with the hood mounted)
an electric socket is available and it is possible to
connect a fumes discharge device to the outside (only
suction version).

•  Carry out all the masonry work necessary (e.g.

installation of an electric socket and/or a hole for the
passage of the discharge tube).

Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified technician must
verify suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood.

Do not tile, grout or silicone this

appliance to the wall. Surface mounting only.

Fig. 4
1.

  Adjust extension of the hood support structure, as the

final height of the hood depends on this.


Note:

 In some cases the upper section of the lattice is

fixed to the lower section with one or more screws,
eventually check and remove them temporarily to allow
the adjustment of the support structure.

2.

  Fix the two sections of the structure with a total of 16

screws (four per corner).

Note:

 If supplied, temporarily remove the screws fixing

the reinforcement bracket to the perforated frame (keep
