www.timberk.com • electrical storage water heater

10

IMPORTANT!

Water can start to drip from the opening of safety  valve
then heating process is going. It’s impossible to avoid
leakage of water and you can’t  prevent this! Locking
of valve may cause rupture of the inner tank in case
of  failure.

IMPORTANT!

“

♥

” position on the control panel corresponds to the

optimum water heating temperature of 58 +/-2°C, at
which:
1. The user is less likely to get burned in case when the
outlet water temperature is incorrectly adjusted.
2. A sufficient amount of hot water is obtained after
mixing with cold water, at a lesser power energy
consumption.
3. Less scale is generated on the heating element and
internal surfaces of the water heater.

3. Turn the thermostate handle (7) (fig. 4) clockwise and set the desirable
temperature. The temperature can be set from +35°C (±5°С) (MIN»
position of the thermostat knob) up to 75°C (±5°С) (rightmost position of
the thermostat knob). To reduce the water temperature turn the handle
anticlockwise.

4. Water  temperature keeps  up  by  the  thermostate automatically. When
water temperature reach the set level, Heating is automatically switched off.
At that, the indicator lamp in the lower part of the appliance extinguishes.
When the temperature be lower then set, the heating will automaticlly start
again and the indicator lamp lights up.

5. To turn off the waterheater, turn the handle to the closest left position
«Off» and unplug the power cord or disconnect the appliance from the power
supply.

IMPORTANT!

The outlet must be designed for rated current not less
than 10A, electric cable with copper core must have
cross section not less than 3x1.5 mm2 (for copper).
