www.timberk.com • electrical storage water heater

6

6.  DELIVERY SET

1. Water heater – 1 pc.

2. Anchor bolt – 2 pcs.

3. Pressure safety valve – 1 pc.

4. Discharge pipe – 1 pc.

5. Operation manual – 1 pc.

6. Guarantee card – 1 pc.

7. Packing – 1 pc.

Fig. 4

1 – left composite protective cover

2 – water containing tanks

3 – system of flows between tanks (3 overflows)

4 – the upper part of the hot water intake tube

5 – heating element

6 – right composite protective cover

7 – temperature sensor case

8 – composite pressure safety valve (be sure to install onto the cold water
supply tube) Pos. A

9 – emergency discharge of surplus water pressure (a small water leakage
is possible from the emergency discharge hole when the water heater is
operating. It is normal)

10 – inlet nozzle with a splitter

11 – hot water outlet nozzle

12 – emergency water discharge nozzle (can be used for water discharge
during cleaning of the internal tank surface upon its maintenance and anode
replacement)

13 – protective magnesium anode

14 – urethane foam heat insulation layer

15 – external decorative case

16 – power cable with GFCI*

* Depending on the product batch, GFCI can be located not within the power cable electric plug.

FSM1/FSQ1 series

1 – the upper composite protective cover

2 – external decorative case

3 – system of flows (3 overflows)

4 – urethane foam heat insulation layer

5 – internal tank

6 – heating element

7 – power cable with GFCI*

8 – thermostat sensor pipe

9 – protective magnesium anode

10 – inlet nozzle with a splitter

11 – the lower composite protective cover

12 – composite pressure safety valve (make sure to install onto the cold
water supply tube) Pos. A

13 – emergency discharge of surplus water pressure (a small water leakage
is possible from the emergency discharge hole when the water heater is
operating. It is normal)

14 – hot water outlet nozzle

15 – the upper part of the hot water intake tube

* Depending on the product batch, GFCI can be located not within the power cable electric plug.
