4.6 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The type of current (alternating current) and voltage at the instal-

lation site have to conform with the data on the type plate  (see

Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.

u

Check the electrical connection.

u

Clean the appliance  (see 6.2) .

u

Plug in the power plug.

4.7 Switching on the appliance

u

Press On/Off button

 Fig. 3 (9).

w

The temperature display and the alarm button flash until the

set temperature is reached.

5 Control

5.1 Brightness of the temperature

display

You can adjust the brightness of the temperature display to the

light conditions of the room in which the appliance is installed.

5.1.1 Adjusting the brightness

The  brightness  is  adjustable  between

h0

  (no  illumination)  and

h5

 (maximum luminosity).

u

To activate the setting mode: press the fan button

 Fig. 3 (10)

for about 5s.

w

The fan button

 Fig. 3 (10) flashes. The display indicates

c

.

u

Using the Up setting button, upper wine zone

 Fig. 3 (8) and

Down setting button, upper wine zone

 Fig. 3 (7) select

h

.

u

To confirm: briefly press the fan button

 Fig. 3 (10).

u

To  set  the  display  brighter:  press  the  Up  setting

button, upper wine zone

 Fig. 3 (8).

u

To  set  the  display  darker:  press  the  Down  setting

button, upper wine zone

 Fig. 3 (7).

u

To confirm: briefly press the fan button

 Fig. 3 (10).

w

The brightness is adjusted to the new value.

u

To  deactivate  the  setting  mode:  press  the  On/Off  button

Fig. 3 (9).

-or-

u

Wait for 5 minutes.

w

The temperature is indicated again in the temperature display.

5.2 Child proofing

The  child-proofing  function  enables  you  to  make  sure  that  the

appliance is not inadvertently switched off by playing children.

5.2.1 Setting the child-proofing function

u

To activate the setting mode: press the fan button

 Fig. 3 (10)

for about 5s.

w

The fan button flashes. The display indicates

c

.

u

Briefly press the fan button

 Fig. 3 (10) to confirm.

u

To  switch  on:  using  the  Up  setting  button,  upper

wine zone

 Fig. 3 (8) or Down setting button, upper

wine zone

 Fig. 3 (7) select

c1

.

u

To  switch  off:  using  the  Up  setting  button,  upper

wine zone

 Fig. 3 (8) or Down setting button, upper

wine zone

 Fig. 3 (7) select

c0

.

u

To confirm: press the fan button

 Fig. 3 (10).

w

The  child-proofing  function  is  switched  on  when  the  child-

proofing symbol

 Fig. 3 (6) shines.

u

To  deactivate  the  setting  mode:  press  the  On/Off  button

Fig. 3 (9).

-or-

u

Wait for 5 minutes.

w

The temperature is indicated again in the temperature display.

5.3 Door alarm

If the door is open longer then 60 s, the audible alarm sounds.

5.3.1 Muting the door alarm

The  audible  alarm  can  be  muted  when  the  door  is  open.  The

sound switch-off function is active as long as the door is left open.

u

Press alarm button

 Fig. 3 (4).

w

The door alarm is silenced.

5.4 Temperature alarm

The audible alarm sounds if the wine storage temperature is too

warm or too cold.
The temperature display flashes at the same time.

The cause of the temperature being too high may be:

-

warm fresh food was placed inside

-

too much warm ambient air flowed in when rearranging and

removing food

-

power failure for some time

-

the appliance is faulty

The audible alarm is automatically silenced and the temperature

display stops flashing when the temperature is sufficiently cold/

warm again.
If the alarm status persists:  (see Malfunction).

Note

Food may be spoilt if the temperature is not cold enough.

u

Check the quality of the food. Do not consume spoiled food.

5.4.1 Muting the temperature alarm

The audible alarm can be muted. When the temperature is suffi-

ciently cold again, the alarm function is active again.

u

Press alarm button

 Fig. 3 (4).

w

The audible alarm is silenced.

5.5 Storing wine bottles

64 Bordeaux bottles (0,75 l) can be stored in the wine zone.

u

Store white wine only in one compartment and red wine only

in  the  other,  since  both  compartments  can  be  set  to  inde-

pendent temperatures.

u

If possible, lay bottles of the same type of wine side by side

on the same grid shelf.

u

Rearrange bottles as seldom as possible.
