u

Stored  open  bottles  on  the

folded  down  wooden  grid

shelf.

u

To fold down the wooden grid

shelf:  press  the  lock  under

the trim sideways.

w

The  wooden  grid  shelf  folds

down.

5.6 Setting the temperature in the wine

zone

The appliance is pre-set for normal operation. The temperature

can be set from 20 °C to 5 °C, the recommended temperatures

are 8 °C to 12 °C.
The wine zone is divided into two wine compartments, which can

be set to different temperatures, as needed.

u

To set the temperature warmer: press the Up setting button,

upper  wine  zone

  Fig.  3  (8)  or  Up  setting  button,  lower  wine

zone

 Fig. 3 (2).

u

To set the temperature colder: press the Down setting button,

upper wine zone

 Fig. 3 (7) or Down setting button, lower wine

zone

 Fig. 3 (3).

u

To  change  the  temperature  in  1  °C  steps:  briefly  press  the

button.

-or-

u

To  change  the  temperature  continuously:  hold  down  the

button.

w

During setting the new value is displayed flashing.

w

The  actual  temperature  is  displayed  about  5  s  after  the  last

press of a button. The temperature slowly adjusts to the new

value.

5.7 Fan

When the fan runs, the relative humidity in the interior increases

so that the cork does not dry out.
When the fan is activated, the energy consumption increases. To

save energy, the fan switches off automatically when the door is

open.

5.7.1 Switching on the fan

u

Briefly press the fan button

 Fig. 3 (10).

w

The fan button

 Fig. 3 (10) shines.

w

The fan always runs. The humidity is high.

5.7.2 Switch off the fan

u

Briefly press the fan button

 Fig. 3 (10).

w

The fan button

 Fig. 3 (10) does not shine.

w

The  fan  runs  only  when  this  is  necessary  for  temperature

control. The humidity is low.

5.8 Labels

You can note down on the labels the type of wine stored in the

respective compartment. Additional labels can be obtained from

your specialist dealer.

5.8.1 Labelling

5.9 Wooden shelf

Pay  attention  that  the  wooden

shelf  does  not  get  caught  on  the

rear hook.

u

To remove the folding wooden

shelf:  lift  it  off  the  pull-out  rail

and draw it forwards.

u

To insert the wooden folding shelf: slide it under the rear hook

and press onto the rails so that they audibly snap into place.

u

To  insert  other  wooden

shelves: place on the rails.

6 Maintenance

6.1 Replacing the activated charcoal

filter

The activated charcoal filter ensures ideal air quality and should

therefore be replaced annually. It can be ordered from a speci-

alised dealer.
Each wine zone is equipped with an activated charcoal filter of

its own.
The activated charcoal filter is fitted at the bottom of the rear wall

of the appliance.

u

Take the activated charcoal filter by the

grip.

u

Turn  the  activated  charcoal  filter

through  90°  to  the  right  or  left

Fig. 29 (1).

u

Remove

 Fig. 29 (2) the activated char-

coal filter.

u

Insert  the  new  activated  charcoal  filter

with the grip in an upright position.

u

Turn  the  new  activated  charcoal  filter

through  90°  to  the  right  or  left

Fig. 29 (1) until it snaps into place.

Fig. 29

6.2 Cleaning the appliance

Before cleaning:

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

NOTICE

Incorrect cleaning damages the appliance!

u

Do not use cleaning agents in concentrated form.

u

Do not use any scouring or abrasive sponges or steel wool.

u

Do  not  use  any  cleaning  agents  containing  sand,  chloride,

chemicals or acid.

u

Do not use chemical solvents.

u

Do not damage or remove the type plate on the inside of the

appliance. It is important for the customer service.

u

Do not pull off, bend or damage cables or other components.

u

Do  not  allow  any  cleaning  water  to  enter  the  drain  channel,

ventilation grille or electrical parts.
