3

O n c e   t h e   h o b   h a s   b e e n   i n s t a l l e d ,   i t   i s
important to remove any protective materials,
which were put on in the factory.

Hob burners control knobs

The hob burners control knobs are situated on the hob
right hand side. The symbols on the knobs mean that:

there is no gas supply

there is maximum gas supply

there is minimum gas supply

Lighting the burners

For easier lighting,  proceed before putting a
pan on the pan support.

Models with semi-automatic ignition

To light a burner, depress the relevant switch
marked with a small spark. Then, push in the
relevant knob and turn it anticlockwise to "maximum
position" (ZGL 646 I).

Contents

This appliance complies with the following
E.E.C. Directives:

- 2006/95

 (Low Voltage Directive);

- 89/336

 (Electromagnetical Compatibility Directive);

- 93/68

 (General Directives)

and subsequent modifications.

MANUFACTURER:

ELECTROLUX HOME PRODUCTS ITALY S.p.A.

Viale Bologna, 298

47100 FORLÌ (Italy)

For the User

For the Installer

Instruction for the User

Important Safety Information

2

Instruction for the User

3

Cleaning and Maintenance

5

Technical Data

6

Instruction for the Installer

6

Electrical Connection

7

Adaptation to different types of gas

8

Building In

9

Possibilities for insertion

10

Fig. 2

A

- Burner cap

B

- Burner crown

C

- Ignition candle

D

- Thermocouple

!

!

!

!

!

•

Fig. 1

The following symbols will be found in the text to guide
you throughout the Instructions:

Safety Instructions

Step by step instructions for an operation

Hints and Tips

Environmental information

Guide to Use the instructions

!

!

!

!

!
