27

GB

Key

This cooking surface allows setting a keypad
lock using the lock button (6). It may be
useful to lock the keypad during operation,
for example for cleaning the control area or,
in any case, if you do not want to change
any settings.
The On/Off button (1) still has priority.

Pause

This cooking surface allows setting a pause
(4) during cooking (which is useful, for
example, when answering a phone call).
When this function is pressed, an LED
lights above the button and the symbol “II”
is displayed in all the cooking areas and the
cooking settings and timers are frozen for
a maximum of 10 minutes, after which the
cooking surface turns off.

Deactivating Pause

Once activated, the functioncan be
deactivated by pressing the pause button
(4) again. The icon (3) flashes and you must
select a cursor area within 10 seconds.
This allows the surface to resume cooking
and the timer starts from the same point at
which it was stopped.

Timer function

There are two versions of the timer function:
- An independent timer from 1 to 99

minutes: it beeps when the time has run
out. This function is available even when
the cooking areas are on.

-  A timer from 1 to 99 minutes for each

cooking area: it beeps when the time has
run out and turns off the cooking area
where it was set. The 4 cooking areas can

be programmed independently.

The timer starts with a default time of 10
minutes and the timer selection point (13)
is active in the cursor area. When you touch
the
minimum level (16), the time decreases and
when you touch the maximum level (17), it
increases.
The type of timer activated is shown in the
dedicated displays (10-12) and the timer
with the least time left is highlighted. If the
least time is related to an independent timer,
the time is simply displayed without any
particular indication while, if the least time
is realted to a cooking area timer, the timer
icon (24) flashes together with the related
indicator light (8-9-14-15). The other timer
settings are still active and running, but will
have a clock icon (24) lit but not flashing.
Just the separator dot (13) is lit when the
timer is selected and modifiable.

Independent timer

- If the touch display is on and all the cooking
areas are at level “0”, the independent timer
can be used by pressing the timer button
(5) and selecting any of the cursors of
any cooking area. If, however, there are
cooking areas switched on, to select the
independent timer, you have to press the
timer button (5) two times and then select
any of the cursors.
If you do not select any button, the timer
deactivates within 10 seconds.
-  The time setting (0-99 minutes) can be

changed in increments of one minute by
keeping your finger in the cursor (17).

-

Holding down the button (16-17)
dynamically increases the rate of change
up to a maximum or minimum value,
without beeps.

-  If the key (16-17) is released, the rate of
