GB

it is necessary to press the PT and KL keys at the same
time, for at least 3 seconds.
The flashing digit to the left of the dot indicates the hours,
while those to the right indicate the minutes. It is possible
to increase or decrease the hours using keys +A or -A
and by keeping keys +A or -A pressed the change in the
number of hours takes place continuously.
To regulate the minutes, press the PT key again. The
digits to the right of the dot will start flashing. Now change
the minutes in the same way as indicated for the hours.
Press the PT key to memorise the time programmed.

Releasing the burner

When a burner is locked the relative display shows the
letter "B". The burner is released by pressing the –A
and KL keys together constantly for at least 2 seconds.
When released, the burners are reset to level 0, ready
to be lit again.
N.B: If the release procedure is repeated 5 times in a row
during a 15 minute time span, the device will indicate
Ft06 and will accept no further request for release for
another 15 minutes.

Locking the control panel

This is activated by pressing the KL key for at least 2
seconds. All burner levels will remain stable. The control
panel locked status occurs when the decimal points on
the display of the capacity level related to each burner
light up. While the control panel is locked it is no longer
possible to change the levels of the burners or change
the timer settings, but it is possible to switch off the hob
by pressing the ON/OFF button.
It is not possible to release a locked burner when the
control panel lock is active. It will be therefore necessary
to release the control panel before activating the burner
release procedure.

Releasing the control panel

The control panel is released by pressing the KL and +A
keys for at least 2 seconds. The control panel is released
when the flame level points on the display go out.

Residual Heat

When a burner goes out, the relative display shows an
"H" to indicate that the temperature of that burner is still
high and the relative LED near the timer display remains
on.
The "H" symbol and the LED turn off when the
temperature of the relative burner is cool.

Special slow cooking (Duty cycle)

This function turns any cook top burner on and off is the
sequence shown in the table.

LEVEL SET.

1

2

3

4

5

TURN-OFF TIME

10

Sec.

20

Sec.

30

Sec.

40

Sec.

50

Sec.

TURN-ON TIME

50

Sec.

40

Sec.

30

Sec.

20

Sec.

10

Sec.

The function is activated by pressing the + key of the
burner you want to apply it to, and the PT key (the burner
involved must be off when this function is activated).
The burner turns on at level 3 and, at that time, you can
set the level to apply the function to by pressing the +
and - keys.
If, for example, you set the value to level 1, the burner
will remain on for 50 seconds, then it will turn off for 10
seconds and repeat this cycle until you turn the burner
off.
If the user does not intervene, the hob switches off
automatically after 60 minutes. When this function is
active, the display of the burner on which it is active
flashes.
