TEchnical passporT

English

Electric hob

 Precaution. It is dangerous

to cook with fat or oil without being

present,  as  these  may  catch  fi re.  Never
try  to  extinguish  a  fi re  with  water!  In

this case disconnect the appliance and

cover the fl ames with a lid, a plate or a

blanket.

 Do not store any object on

the cooking areas of the appliance .

Preventa possible fi re hazard.

 Do not use plastic pots or

alliminium sheets

 Do not use hob as a

supplamentary surface

 Dry the bottom of the pot before

put in on the cooking zones

 Do not scrape the pot against

the glass to avoid damaging it

 Use pots with the same diameter

of cooking zones

U S E

COOKTOP CONTROLLED BY

TOUCH CONTROL

The graphical display is shown in

fi gures 1,2,3 . As you see, the diameters

and thus the powers of heating elements

vary  as  shown  in  Table  1.  Heating

elements are controlled by this control
unit with 9 positions. When supply
voltage is applied the hob control unit
carries out an automatic calibrat ion
procedure. The hob is thereafter in
stand-by mode.

All  the  heat  zones  are  switched  off

and t he display are not illum inated.

The desired heating element can

now be selected by using the 4,5,6 or
7 sensors for related heating elements

(see  fi g.  1,2,3).  Heat  settings  of  the

selected heating element adjusted by
using the (-) sensor which is shown

as»3»in  Figure  1  to  reduce,  (+)  sensor
which  is  shown  as  «2»in  F  igure  1  to

increase the heat level.

There are 9 heat setting modes

starting from 1 to 9. «1» is the minimum

and «9» is the maximum mode.

You can see the suggested cookings

in Table 2.

When a heating element has been

switch off by means of on/off sensor, an

«H»  appears  on  the  illustrated  display

to show that the heating element is still

hot for 30 minutes in order to avoid any

accident.

For  the  hobs  included  dual  zone

heating elements.

Outer  part  of  dual  zone  heating

element could not work separately.
There are two possibility, one is using
inner part of the heating and the other
one is using both. Inner part of it can
be activated by pushing related control
unit however to activate the whole
heating element, it is needed to push

related  control  unit  for  inner  part  fi rst

and then related control unit of outer
part.
