11

English

TEchnical passporT

Electric hob

When the connection to the input

system has been done through an outlet



Apply to t he input cable,

rf  unprovided,  a  normalized  plug

adequate to the load indicated in the

identifi cation  label.  Connect  the  cables
according to the scheme of Fig. 13.

Letter L (live)=cable brown colour;

Letter N (Neutral)=cable blue colour,

Symbol

 (Earth) = cable green

-yellow colour.



 The input cable has to

be located so that never reach the
temperature over 75 K.



 Please do not use in the

connection any reduction, adaptation
that may provoke a false contact with
following dangerous overheatings.



 The outlet must be accessible

after the built-in.

When the connection has been

done the input system:



Interpose between the

appliance and the system an omnipolar
switch, adequate to the load of the

appliance, with a minimum gap of 3mm

between the contacts.



Keep in mind that the «earth»

cable does not have to be interrupted
by the switch.



In an alternative solution

the electrical connection can also
be

protected by a differential switch with

high sensitivity.

We  recommend  to  fi x  the  earth

coloured cable to an appropriate earth
installation.

WARNINGS:

All our products a re projected and

built in accordance with the European
Norms EN 60 335-1 and EN 60 335-2-6
and relative amendments.

The appliance has been produced

in accordance with the European
Directives:

- 2004/108/EC concerning the

electromagnetic compatibility.

- 2006/95/EC concerning the

electrical security.

TRANSFORMATIONS

Before any kind of transformation, it

is necessary to cut off the electricity.

TRANSFORMATION
OF THE INPUT TYPE

The standard equipment of

the appliances is for single phase
connection. In any case, under proper
changes, they can be fed with a three
phase system.
