Coffe reductor



(only available with some models)

Use the extension when using a pan of a smaller diameter.
Place the extension on the grid above the auxiliary burner.







Cookware





















• Correctly selected cookware will enable optimum cooking time and gas consumption.
Pan diameter is the most important parameter.
• Use pans which are the right size for each burner. Do not use small pans on large
burners. The flame should not touch the sides of the pan.
• For combustion, the gas also needs air. If a pan is too large, air supply to the burner is
insufficient; as a result, combustion effect is lesser.
• Always place the pan right over the burner, not to one side. Otherwise it could tip over.
Do not place large pans on the burners near the control knobs. These may be damaged
by the very high temperatures.
• Never use two burners or heat sources to heat one single pan. Do not use grill pans,
earthenware casserole dishes, etc. for a long period of time on maximum power specially
on cristall glass gas hobs.
• Pans should be placed on the hob carefully. Do not strike the hob and do not place
excessive weight on it.
• Place the pans on the pan supports, never directly on the burner. Make sure that the
pan supports and burner caps are correctly positioned before using the appliance.
• Stainless steel working table can burnish when subjected to excessive heat. Therefore
we don’t recommend prolonged cooking with soapstone, earthenware pans or cast iron
plates.  Avoid the use of aluminum foil to protect the working table during cooking
operation.
• Do not use cast iron plates or griddles for cooking or heating food on the burners (check
the sizes of pot allowed for each kind of burner) specially on cristall glass gas hobs
• Cooktop should not be used as a worktop. Sharp objects can cause scratches.
• Preparing food in thin aluminum of plastic containers on hot cooking zones is not
allowed. Do not place any plastic objects or aluminum foil on the cooktop.
• If sugar is spilt on a hot cooktop, or a sugar-laden food, immediately wipe the hob.



Burner Qn

BURNER

Min-Max Pan Ø

Auxiliary 1,00

kW

120 - 180 mm

SR

Semirapid 1,75

kW

180 - 220 mm

Rapid 3,00

kW

220 - 240 mm

MW

Mini-Wok 3,30

kW

220 - 260 mm

TC

Triple ring

3,80 kW

220 - 260 mm



OPERATION



Hob control elements
for gas cooking zones












Gas valve closed



Ignition

Maximum power

Minimum power




Ignition and operation
of the burners







User’s instructions

This appliance must be used for the purpose it was designed for, i.e. domestic cooking.
Any other use is considered to be improper and therefore dangerous.
The manufacturer will accept no liability for any damage caused by improper, incorrect or
irrational use.



Using the burners

•  If the burners are not used for several days, wait a few seconds before lighting them in

order to release any air from the pipes.

•  As the cook top burners are fitted with an automatic ignition, to light them simply press

and turn the handle to the small star. The appliance uses a spark ignition generator.

•  If the flame does not ignite within five seconds, turn the knob back to the 0 position and

repeat the procedure; if the electric ignition should not work due to a power failure or
damp spark plugs, the gas can also be ignited using a match or a gas lighter.
