60

USING THE HOB

Before you begin, it is important to know:

All functions of this cooktop are designed to comply with the
most stringent safety regulations.
For this reason:

• Some functions will not be activated, or will be
automatically deactivated, in the absence of pots on the
burners or when they are poorly positioned.

• In other cases the activated functions will be automatically
deactivated after a few seconds, if the specific function
requires a further setting that has not been selected (e.g.:

“Turn the cooktop on”

without

 “Selecting the cooking

zone”

 and the

 “Operating temperature”,

or the

 “Lock

Function”

or the

 “Timer”

 function).

  Caution!

In the case (for example) of prolonged use,

the cooking zone may not immediately shut down because it
is in the cooling phase; the  “ ” symbol will appear on the

cooking zone display, to indicate the execution of this phase.
Wait for the display to turn off before approaching the cooking
zone.


Cooking zone display

The following is shown on the cooking zone displays:




Cooking zone on

Power Level

 …   -


Residual Heat Indicator



Pot Detector



Temperature Manager Function
active



Lock function active


Pause function


Automatic Heat UP function

Hob characteristics


 Safe Activation

The product is activated only in the presence of pots on the
cooking zone: the heating process does not start or is
interrupted if there are no pots, or if these are removed.


 Pot Detector

The product automatically detects the presence of pots on the
cooking zones.

 Safety Shut Down

For safety reasons, each cooking zone has a maximum
operating time, which depends on the maximum power level
set.

 Residual Heat Indicator

When one or more cooking zones shut down, the presence of
residual heat is indicated by a visual signal on the
corresponding zone display, by way of the “ ” symbol.


Operation
Note:

 Before activating any functions, the desired zone must

be activated

 Switch-on

Press (touch) briefly

ON/OFF (1)

hob/extractor: the symbol

 lights up;

continuing to press

, all the available functions will become

visible for a few moments, e

, after which

 only the main

ones will remain active; the others can be used, and will
be activated, subsequently, during use of the device.

IMPORTANT:
all the available functions will be illuminated with light
intensity, which will become more intense only when they
are activated.

Press

 again to turn off

Note: This function has priority over the others.



 Selecting the cooking zones

Press (touch) briefly the

 Selection/Display (2)

 area

corresponding to the desired cooking area.

 Power Level

The hob features 9 power levels
Touch and slide your fingers along the

Selection bar (3):

to the right to increase the level of power;
to the left to decrease the level of power.

The power level set will be displayed in the
Selection/Display area (2)
