EN - 18

14. TROUBLESHOOTING

PROBLEM

PROBABLE CAUSE

SOLUTION

1.

When the safety

button is pressed,

the two green lights

do not come on

Battery is not inserted or

is inserted incorrectly

Make sure the battery is inserted and

well fit in its housing (paragraph 7.2.3)

2.

Pushing the safety

button, the LED

(Fig. 7.G) blinks

Low battery

Check the battery status and

recharge if necessary (par. 7.2.2)

3.   The motor stops during

work and

the LED

 (Fig. 7.G) blinks

Low battery

Check the battery status and

recharge if necessary (par. 7.2.2)

4.

The cutting means is

stationary when the

throttle control lever

and throttle safety

lever are engaged

Machine damaged

Do not use the machine. Immediately

turn off the machine remove the battery

and contact a service centre.

5.  Motor overheating

Grass caught under the

cutting means guard

Remove caught grass (par. 6.5)

6.

Mowing is difficult

The cutting means is not

in good condition

Proceed with cutting means

maintenance (par. 8.1)

7.

Grass accumulates

around the rod housing

and cutting line head

Too high grass is being cut

close to the ground

Cut tall grass with a top down

movement to avoid accumulations.

8.  The line is not released

when the cutting line

head hits the ground

The line is stuck to itself

Lubricate with silicone spray

Not enough line on the

reel or reel empty

Replace the line (chapter 8.1.3.)

The line is worn and too short

Pull the line while pressing the release button

The line is tangled on the reel or broken Remove the line from the reel

and

rewind it (chapter 8.1.3)

9.

The cutting means

comes into contact

with a foreign body.

-

Turn off the machine, remove the battery and:

- inspect for damage;

- check for and tighten any loose parts;

- have all replacements or repairs carried

out by an authorised service centre.

10.  Excessive noise and/or

vibration is experienced

whilst working

Loose or damaged parts.

Turn off the machine, remove the battery and:

- inspect for damage;

- check for and tighten any loose parts;

- have all replacements or repairs carried

out by an authorised service centre.

11.

The machine gives off

smoke whilst working

Machine damaged

Do not use the machine. Immediately

turn off the machine remove the battery

and contact a service centre.

12.

Battery power

reserve is low

Severe working conditions

requiring greater

current absorption

Optimise operations

(par. 7.2.1)

Battery is insufficient for

operating requirements

Use a second battery or

extended

battery (par. 15.1)

Decrease in battery capacity

Purchase a new battery

If problems persist after having performed the operations described above, contact your dealer.
